Measured values clearly incorrect

Table 12: Measured values clearly incorrect
Possible errors
Sample gas penetrated the area
before the SR-unit.
Sample gas penetrates the purge air
compartment.
Sample gas conditions do not
match, or no longer match, project
planning
The device is not ready for opera‐
tion.
The device is not adjusted correctly.
Analyzer is contaminated.
10.6

Sample gas penetrating

Table 13: Sample gas penetrating
Possible errors
Sample gas penetrates the area
before the SR-unit.
Sample gas penetrates the GMP
measuring probe.
10.7

Corrosion on measuring probe or flange

Table 14: Corrosion on measuring probe / flange
Possible errors
Corrosion on measuring probe or
flange
10.8

Measured value blinks

Error
One measured value blinks
8015558/1O6S/V1-9/2024-08 | SICK
Subject to change without notice
Possible causes
•
The gas pressure in the gas duct
is too high
•
Purge air supply has failed or is
too weak
• The gas pressure in the gas duct
is too high
• Purge air supply has failed or is
too weak
• Probe gap alignment incorrect.
The sample gas flow must not be
pressed into the purge air open‐
ings
•
Plant condition has changed
--
--
--
Possible causes
•
The gas pressure in the gas duct
is too high
• Purge air supply has failed or is
too weak
• Purge air supply has failed or is
too weak
Possible causes
Unsuitable materials
Possible causes
• Measured value is "uncertain" (e.g.
calibration range exceeded).
TROUBLESHOOTING
Action
see "Sample gas penetrating", page
see "Sample gas penetrating", page
Check installation.
►
Check sample gas conditions (temperature,
►
moisture, concentration etc.).
Check start-up.
►
Check status/error messages.
►
Check:
►
– Were correct test gases used?
– Are setpoint values correct?
If the answer to both questions is "Yes", con‐
►
tact SICK Service to have a calibration per‐
formed.
Report to manufacturer's Technical Service or
►
trained skilled persons.
Action
Check project planning.
►
Check purge air supply.
►
Provide redundant purge air supply.
►
Increase purge air supply.
►
Action
Replace measuring probe.
►
Remedy
Check the calibration range.
►
