Table 17: Error table: Maintenance request / Xtended
Initiator Text
EL. too hot
Air purge low
Filter watch
p no signal
p out of range
Probe
t air no signal
[t] no signal
EEPROM
defect
No com.
Systemstart
Zero adjust
Boxmeasuring
System
Reflector
search
Substitute
P
value
T
H
8015558/1O6S/V1-9/2024-08 | SICK
Subject to change without notice
Classifica‐ Description
tion
Electronics too hot.
Maint.
Maint. Volume flow below set limit.
Maint. Flow monitor.
Maint. No signal from pressure sensor.
Sample gas pressure < 500 or > 1200 hPa
Maint.
(mbar).
Maint. Broken sensor
Maint.
EEPROM defective.
Maint.
Communication error to optic head and/or
Maint.
reflector.
This message is entered during each system
Xtended
start.
The start of an adjustment is recorded in the
Xtended
logbook.
The start of filter box measurement is
Xtended
recorded in the logbook.
Search for reflector failed.
Xtended
Calculation is made with a substitute value
Maint.
because of a pressure measurement error.
Maint.
Maint.
TROUBLESHOOTING
Possible causes/remedy
•
Allow device to cool down.
•
Ambient temperature too high?
Check purge air supply.
---
Please contact SICK Customer Service.
Check connection cables.
Shows when last system start was made.
Shows when last adjustment was made.
Shows when last filter box measurement was
made.
•
Check the alignment.see "Alignment check
(option) - automatic optical alignment
check", page 56
•
Reflector contaminated or defective.
• Light intensity weakness too strong on
measuring path.
