Diagnosis

Status messages, status indicators and system states
Table 8: 1
Status LED
Power on
(main supply volt‐
age on)
Uncertain
(Uncertain)
Measured
value blinks
Maintenance
request
(maintenance
request message)
Failure
(malfunction)
Option
1
Option. Refer to the delivered System Documentation for the assignment of the status outputs.
2
3 See SOPAS ET in the "Digital outputs" menu.
8.2.4.2

Check cycle - results of last check cycle

8015558/1O6S/V1-9/2024-08 | SICK
Subject to change without notice
Subnet mask
Gateway
Maintenance,
mode ", page
The "Diagnosis" menu shows the current error messages.
the following information is available for troubleshooting:
• The GM32 signals a malfunction or an unsafe operational state with status signals
(option). See electrical connection diagram.
• Logbook: Access to the logbook via SOPAS ET,
page 16.
•
List of error messages and measures for clearing malfunctions,
sages", page 75.
Significance
Power supply in order
• Measured value uncertain (e.g. outside calibration
range)
• Cause: Press the DIAG button
• All messages in the SOPAS ET logbook
• Troubleshooting, see "Error messages", page 75
• Irregularities (e.g. gas temperature too high, deviation
from check cycle too high) that require a review of the
cause
• The measured values are valid
• Press the DIAG button: Error display
• All messages in the SOPAS ET logbook
• Troubleshooting, see "Error messages", page 75
•
Device failure (e.g. lamp failed)
•
Cause: Press the DIAG button
•
All messages in the SOPAS ET logbook
• Troubleshooting, see "Error messages", page 75
NOTE
The results of the last check cycle can be called up in this menu item.
see "Maintenance mode - set Maintenance
58.
see "SOPAS ET (PC program)",
Measured
value display
--
Current
Current
Last valid measured value
held
O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
8
OPERATION
see "Error mes‐
Analog out‐ Status signal
puts
1 2,3
According to
setting
