12
TECHNICAL DATA
12.4

Connection unit, Ex version I/O module

12.5

Electric isolation of evaluation unit

86 O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
Description
Analog outputs
Analog inputs
Digital outputs
Digital inputs
Interfaces
Bus protocol
Dimensions (W x H x D)
Weight
Electrical connection
Connections SCU I/O
Relay contact <-> PE
Relay contact <-> relay contact
Relay contact <-> actuation
Serves for on-site connection of the power supply and of data
and signal cables
2 outputs:
0/4 ... 22 mA, 500 Ω
Per module, modules can be selected and extended as
required
2 inputs:
0/4 ... 22 mA, 100 Ω
Per module, modules can be selected and extended as
required
4 outputs:
48 V AC/DC, 0.5 A, 25 W
Per module, modules can be selected and extended as
required
4 inputs:
3.9 V, 4.5 mA, 0.55 W
Per module, modules can be selected and extended as
required
Ethernet via fiber optical cable
Extendable via external control unit (option)
•
OPC
•
Ethernet TCP/IP (only via fiber optic cable connection)
679 mm x 630 mm x 158 mm
≤ 16 kg
• Voltage: 115 V or 230 V (application-specific)
• Frequency: 50 Hz / 60 Hz
• Power input: ≤ 260 W
860 V AC
860 V AC
1376 V AC
