TECHNICAL DATA
12.7

Dimension drawings of open measuring probe (GMP)

227
A
10
76,4
A
Figure 42: GMP measuring probe (all specifications in mm)
GMP measuring probes
Probe length, L1
normal
900 935
1.500 1.644
2.000 2.128
2.500 2.628
Application-specific lengths on request
All dimensions in mm
88 O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
L2
Ø 200
176,9
144
Measuring gap L3 (active measuring path)
250 500 750
296 -- --
1.004,5 754,5 504,5
1.489 1.239 989
1.988 1.738 1.488
L1
L3
Ø 254
Ø 200
B
Ø 215,8
1.000 1.250
-- --
254,5 --
739 489
1.238 988
B
1.500 1.750
-- --
-- --
239 --
738 488
