7
COMMISSIONING
48
O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
1
4
5
Figure 26: Hinge of the sender/receiver unit
1
Fit the SR-unit on the device flange into the hinge.
NOTE
Recommendation: Install the flange on the left.
The device flange can be installed on the left or right. The advantage of installa‐
tion on the left is the unhindered access to the device display when working on the
swiveled out flange.
2
Insert the hinge pin from above in the hinge.
NOTICE
If the hinge pin has not been correctly inserted, the SR-unit can drop when swiv‐
eled out.
Ensure the hinge pin is fully inserted.
3
Check the window for cleanness and clean, if required,
page
65.
4
Check the desiccant cartridge for dryness,
cant cartridges", page
5
Close the SR-unit with the 4 quick-release fasteners.
6
GMP measuring probe: Set the lever on the purge air fixture to position "open".
Figure 27: Locking device lever
2
3
see "Checking and replacing the desic‐
65.
Hinge
1
Hinge pin
2
Device flange
3
Window
4
Desiccant cartridge
5
see "Cleaning the window",
8015558/1O6S/V1-9/2024-08 | SICK
Subject to change without notice
