ELECTRICAL INSTALLATION
6.4

Connecting the connection hose to the S/R unit on the junction box

36 O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
Analog output Pin assignment
AO1 11, 12
AO 2 21, 23
Digital output Pin assignment
DO 1 11, 12
DO 2 21, 22
DO 3 13, 14
DO 4 23, 24
DO 5 11, 12
DO 6 21, 22
DO 7 13, 14
DO 8 23, 24
Configurable Configurable
1 On second module
Digital input Pin assignment
DI 1 11, 12
DI 2 21, 22
DI 3 13, 14
DI 4 23, 24
DI 5 11, 12
DI 6 21, 22
DI 7 13, 14
DI 8 23, 24
1 On second module
NOTE
Information concerning the customer-specific module assignment
The module layout from the left to the right always has the sequence: AO-AI-DO-DI
■
The number of inlets and outlets is defined:
■
– AO: 2x
– AI: 2 x
– DO: 4 x
– DI: 4 X
Second measuring range: AO is always on the right next to the respective compo‐
■
nent.
NOTICE
The connecting hose between the SR-unit and the junction box is part of the pressur‐
ized enclosure. It is under overpressure.
Protect the connecting hose from possible damage.
►
Function
User-specific
User-specific
Function
Failure
Maintenance_Request
Not_measuring
Output_control_values
Uncertain
1
Extended
1
1 Purge_air_failure
No_function
1
Measuring range switch-over (see GM32 Tech‐
nical Information)
Function
Check_cycle
Maintenance
Output_control_values
Disable_check_cycle
Purge_air_status
1
1 --
--
1
1 --
