13

ANNEX

13 Annex
13.1

Conformities

13.2

Electrical protection

13.3

Ex certifications

92 O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
GM32 Ex complies with the following directives and standards:
Table 21: Applied EN standards for measuring systems
EN standard Application
EN 14181 Calibration of continuously operating emission measuring instru‐
ments
EN 15267-3 Part 3 - Certification of automatic measuring systems
EN 60068 Shock and vibration
Table 22: Ex-relevant directives and standards
Directive Harmonized standard
2014/34/EU ATEX EN / IEC 60079-0:2018
IEC / EN 60079-2:2014/2014
IEC / EN 60079-11:2011/2012 Protection through intrinsic safety
IEC / EN 60079-28:2015/2015 Optical radiation
2014/30/EU EMC IEC / EN 61326-1:2012/2013
2014/35/EU Low Volt‐ IEC / EN 61010-1:2010/2010
age Directive
EN 60529:1991+ A1:2000 +
A2:2013
•
Device corresponds to protection class 1 and requires a protective grounding (PE)
in accordance with EN 61140
• Overvoltage protection in accordance with EN 61010-1
• Contamination: The control unit operates safely in an environment up to contami‐
nation level 2 in accordance with EN 61010-1 (usual, non-conductive contamina‐
tion and temporary conductivity by occasional moisture condensation)
3G / Zone 2: Connection unit and sender/receiver unit
ATEX GM32 Ex 3G
•
X II 3G Ex pzc op is [ia] IIC T3 Gc
IECEx GM32 Ex Zone 2
• Ex pzc op is [ia] IIC T3 Gc
Special conditions (X identification)
Application
General requirements
Pressurized enclosure Ex-p
Ex i
EMC for electrical measuring devi‐
ces
Safety requirements for electrical
equipment for measurement, con‐
trol, and laboratory use
Degrees of protection provided by
enclosures (IP code)
