5
MOUNTING
5.3

Scope of delivery

5.3.1

Checking the delivery state

5.4

Installation sequence

5.4.1

Overview of the installation steps (duct-side preparation)

5.4.2

Installing the flange with tube

26 O P E R A T I N G I N S T R U C T I O N S | GM32 Ex
DANGER
Risk of explosion through suctioning optics purge air from an Ex zone
Zone separation is no longer ensured when the purge air supply to purge the optics is
suctioned in within the Ex zone. This can lead to an explosion.
Always make sure the air for the purge air supply is suctioned in from an Ex free
►
zone.
WARNING
Observe zone separation,
NOTICE
Check the scope of delivery according to the order confirmation/delivery note.
►
NOTICE
Check all components have no exterior damage.
►
Ensure the supply voltages on the type plates match the plant conditions.
►
Step Procedure
1 Installing the flange with tube.
2 Installing the connection unit.
3 Connecting the instrument air adapter.
4 Observing protective gas discharge line (con‐
nection unit).
5 Connecting pressure and temperature moni‐
tor.
6 Connecting protective gas feed to SR-unit.
DANGER
Hazard through hot, explosive or toxic flue gases
Hot and/or noxious gases can escape during assembly work on the gas duct depending
on plant conditions.
Work on the gas duct may only be performed by skilled persons who, based
►
on their technical training and knowledge as well as knowledge of the relevant
regulations, can assess the tasks given and recognize the hazards involved.
see "Zone separation GM32 Ex ATEX 3G", page
Reference
see "Installing the flange with tube",
page
see "Installing the connection unit",
page
see "Connecting the instrument air
adapter", page
see "Fitting the FS850S", page
see "Connecting pressure, temperature
and purge air monitor ", page
see "Connecting the protective gas on
the SR-unit", page
20.
26.
27.
29.
28.
37.
45.
