Proline Prosonic Flow I 400 Modbus RS485
Parameter
Output current
Measured current
Pulse output 1 to n
Output frequency 1 to n
Switch state 1 to n
Parameter
Totalizer 1 to n value
Totalizer 1 to n overflow
Endress+Hauser
Parameter overview with brief description
Prerequisite
–
–
The Pulse option is selected in the
Operating mode parameter parameter.
In the Operating mode parameter, the
Frequency option is selected.
In the Operating mode parameter, the
Switch option is selected.
11.4.5

"Totalizer" submenu

The Totalizer submenu contains all the parameters needed to display the current
measured values for every totalizer.
Navigation
"Diagnostics" menu → Measured values → Totalizer
‣
Totalizer
Totalizer 1 to n value
Totalizer 1 to n overflow
Parameter overview with brief description
Prerequisite
One of the following options is selected
in the Assign process variable
parameter (→  105) of the Totalizer
1 to n submenu:
• Volume flow
• Mass flow
One of the following options is selected
in the Assign process variable
parameter (→  105) of the Totalizer
1 to n submenu:
• Volume flow
• Mass flow
11.5

Adapting the measuring device to the process

conditions

The following are available for this purpose:
• Basic settings using theSetup menu (→  74)
• Advanced settings using theAdvanced setup submenu (→  103)
Description
Displays the current value currently
calculated for the current output.
Displays the current value currently
measured for the current output.
Displays the pulse frequency currently
output.
Displays the value currently measured
for the frequency output.
Displays the current switch output
status.
Description
Displays the current totalizer counter
value.
Displays the current totalizer overflow.
Operation
User interface
3.59 to 22.5 mA
0 to 30 mA
Positive floating-point
number
0.0 to 12 500.0 Hz
• Open
• Closed
→  121
→  121
User interface
Signed floating-point
number
Integer with sign
121
