Preparing the measuring device

1. Remove all remaining transport packaging.
2. Remove stick-on label on the electronics compartment cover.
6.2.3

Mounting the sensor

Sensor configuration and settings
Single-path version
[mm (in)]
Sensor distance
Path length →  9,  25
1)
Depends on the conditions at the measuring point (e.g. measuring pipe). The mounting position of the
sensor can be determined via FieldCare or Applicator. See also Result Sensor Type / Sensor Distance
parameter in Measuring point submenu
Determining the mounting positions of the sensor
Description of installation
1
2
b
 9
Terminology Description of installation
1
Single-path version
2
Two-path version
a
Sensor distance
b
Arc length
c
Path length
d
External diameter of measuring pipe
Detailed information:
DN 200 to 4000 (8 to 160")
1)
a
c
a
c
Mounting procedure
Two-path version
[mm (in)]
1)
Sensor distance
Path length →  9,  25
Arc length →  9,  25
b
A0044950
25
