Navigation view

In the submenu
1
2
/../Operation
Access stat.disp
Locking status
Display
5
1 Navigation view
2 Navigation path to current position
3 Status area
4 Display area for navigation
5 Operating elements →  50
Navigation path
The navigation path to the current position is displayed at the top left in the navigation
view and consists of the following elements:
• The display symbol for the menu/submenu ( ) or the wizard ( ).
• An omission symbol (/ ../) for operating menu levels in between.
• Name of the current submenu, wizard or parameter
Display symbol
↓
Example
For more information about the icons in the menu, refer to the "Display area" section
→  47
Status area
The following appears in the status area of the navigation view in the top right corner:
• In the submenu
• The direct access code to the parameter (e.g., 0022-1)
• If a diagnostic event is present, the diagnostic behavior and status signal
• In the wizard
If a diagnostic event is present, the diagnostic behavior and status signal
• For information on the diagnostic behavior and status signal →  129
• For information on the function and entry of the direct access code →  52
Display area
Menus
Symbol Meaning
Operation
Is displayed:
• In the menu next to the "Operation" selection
• At the left in the navigation path in the Operation menu
2
3
0091-1
Operator
4
5
A0013993-EN
Omission symbol
↓
/ ../
Operation options
In the wizard
1
/../Curr. output 1
Assign curr.
Volume flow
Parameter
↓
Indication
S
3
4
A0016327-EN
