Operation options
50
Moves the input position one position to the right.
Moves the input position one position to the left.
Deletes one character immediately to the left of the input position.
8.3.4

Operating elements

Operating key
Meaning
Minus key
In menu, submenu
Moves the selection bar upwards in a picklist
In wizards
Goes to previous parameter
In the text and numeric editor
In the input screen, moves the selection bar to the left (backwards)
Plus key
In menu, submenu
Moves the selection bar downwards in a picklist
In wizards
Goes to the next parameter
In the text and numeric editor
In the input screen, moves the selection bar to the right (forwards)
Enter key
In the operational display
Pressing the key for 2 s opens the context menu including the option for activating the
keypad lock.
In menu, submenu
• Pressing the key briefly:
• Opens the selected menu, submenu or parameter.
• Starts the wizard.
• If help text is open, closes the help text of the parameter.
• Pressing the key for 2 s in a parameter:
If present, opens the help text for the function of the parameter.
In wizards
Opens the editing view of the parameter and confirms the parameter value
In the text and numeric editor
• Pressing the key briefly:
• Opens the selected group.
• Carries out the selected action.
• Pressing the key for 2 s confirms the edited parameter value.
Escape key combination (press keys simultaneously)
In menu, submenu
• Pressing the key briefly:
• Exits the current menu level and takes you to the next higher level.
• If help text is open, closes the help text of the parameter.
+
• Pressing the key for 2 s returns you to the operational display ("home position").
In wizards
Exits the wizard and takes you to the next higher level
In the text and numeric editor
Closes the text or numeric editor without applying changes.
Minus/Plus/Enter key combination (press the keys simultaneously)
+
+
In the operational display
Enables or disables the keypad lock (only SD02 display module).
