Operating Mode (0469); Assign Pulse Output (0460) - Endress+Hauser Proline Prosonic Flow I 400 Operating Instructions Manual

Commissioning
Parameter
Operating mode
Assign pulse output
Pulse scaling
Pulse width
Failure mode
Invert output signal
* Visibility depends on order options or device settings
92
Configuring the pulse output
Navigation
"Setup" menu → Pulse/frequency/switch output 1 to n
‣
Pulse/frequency/switch output
1 to n
Operating mode
Assign pulse output
Value per pulse
Pulse width
Failure mode
Invert output signal
Parameter overview with brief description
Prerequisite
–
The Pulse option is selected in
Operating mode parameter.
The Pulse option is selected in
the Operating mode
parameter (→  92) and a
process variable is selected in
the Assign pulse output
parameter (→  92).
The Pulse option is selected in
the Operating mode
parameter (→  92) and a
process variable is selected in
the Assign pulse output
parameter (→  92).
The Pulse option is selected in
the Operating mode
parameter (→  92) and a
process variable is selected in
the Assign pulse output
parameter (→  92).
–
Proline Prosonic Flow I 400 Modbus RS485
Description
Define the output as a pulse,
frequency or switch output.
Select process variable for
pulse output.
Enter quantity for measured
value at which a pulse is
output.
Define time width of the
output pulse.
Select output behavior in the
event of a device alarm.
Invert the output signal.
→  92
→  92
→  92
→  92
→  92
→  92
Selection / User Factory setting
entry
*
• Pulse –
*
• Frequency
*
• Switch
• Off –
• Volume flow
• Mass flow
Positive floating Depends on country
point number and nominal
diameter
0.05 to 2 000 ms –
• Actual value –
• No pulses
• No –
• Yes
