Page 1 Products Solutions Services BA01875D/06/EN/03.24-00 71675090 2024-11-01 Valid as of version 01.00.zz (Device firmware) Operating Instructions Proline Promass I 500 Coriolis flowmeter PROFIBUS DP...
Page 2 • The manufacturer reserves the right to modify technical data without prior notice. Your Endress+Hauser sales organization will supply you with current information and updates to this manual. Endress+Hauser...
Page 3 Proline Promass I 500 PROFIBUS DP Table of contents Table of contents About this document ....6 Installation ..... . . 21 Document function .
Page 4 Table of contents Proline Promass I 500 PROFIBUS DP Access to operating menu via local display . . . 65 Commissioning ....104 8.3.1...
Page 5 13.2 Measuring and test equipment ... 246 13.3 Endress+Hauser services ....246 Repair ......247 14.1 General notes .
Page 6 About this document Proline Promass I 500 PROFIBUS DP About this document Document function These Operating Instructions contain all the information required in the various life cycle phases of the device: from product identification, incoming acceptance and storage, to installation, connection, operation and commissioning, through to troubleshooting, maintenance and disposal.
Page 7 Proline Promass I 500 PROFIBUS DP About this document 1.2.4 Tool symbols Symbol Meaning Torx screwdriver Phillips head screwdriver Open-ended wrench 1.2.5 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted. Preferred Procedures, processes or actions that are preferred.
Page 8 • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. The following documentation may be available depending on the device version ordered: Document type...
Page 9 Proline Promass I 500 PROFIBUS DP Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10 Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11 Proline Promass I 500 PROFIBUS DP Safety instructions Device-specific IT security The device offers a range of specific functions to support protective measures on the operator' s side. These functions can be configured by the user and guarantee greater in- operation safety if used correctly.
Page 12 Safety instructions Proline Promass I 500 PROFIBUS DP WLAN passphrase: Operation as WLAN access point A connection between an operating unit (e.g. notebook or tablet) and the device via the WLAN interface (→  85), which can be ordered as an optional extra, is protected by the network key.
Page 13 Proline Promass I 500 PROFIBUS DP Product description Product description The measuring system consists of a transmitter and a sensor. The transmitter and sensor are mounted in physically separate locations. They are interconnected by connecting cables. Product design Two versions of the transmitter are available.
Page 14 Product description Proline Promass I 500 PROFIBUS DP For use in applications required to meet special requirements due to ambient or operating conditions. As the electronics are located in the transmitter, the device is ideal in the event of: • Strong vibrations at the sensor.
Page 15 • Enter the serial numbers from the nameplates in the Device Viewer (www.endress.com/deviceviewer): all the information about the device is displayed. • Enter the serial numbers from the nameplates into the Endress+Hauser Operations app or scan the DataMatrix code on the nameplate with the Endress+Hauser Operations app: all the information about the device is displayed.
Page 16 Incoming acceptance and product identification Proline Promass I 500 PROFIBUS DP 4.2.1 Transmitter nameplate Proline 500 – digital Order code: Ser. no.: Ext. ord. cd.: Date: A0029194  3 Example of a transmitter nameplate Name of the transmitter Manufacturer address/certificate holder...
Page 17 Proline Promass I 500 PROFIBUS DP Incoming acceptance and product identification Proline 500 3 4 5 Order code: Ser. no.: Ext. ord. cd.: Date: A0029192  4 Example of a transmitter nameplate Manufacturer address/certificate holder Name of the transmitter Order code Serial number (Ser.
Page 18 Incoming acceptance and product identification Proline Promass I 500 PROFIBUS DP 4.2.2 Sensor nameplate Order code: Ser. no.: Ext. ord. cd.: Date: A0029199  5 Example of a sensor nameplate Name of the sensor Manufacturer address/certificate holder Order code Serial number (Ser. no.) Extended order code (Ext.
Page 19 Proline Promass I 500 PROFIBUS DP Incoming acceptance and product identification 4.2.3 Symbols on the device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Please consult the documentation for the measuring instrument to discover the type of potential danger and measures to avoid it.
Page 20 Storage and transport Proline Promass I 500 PROFIBUS DP Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 21 Proline Promass I 500 PROFIBUS DP Installation 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device. ‣ The device must always be secured at two lifting lugs at least.
Page 22 Installation Proline Promass I 500 PROFIBUS DP Installation in down pipes However, the following installation suggestion allows for installation in an open vertical pipeline. Pipe restrictions or the use of an orifice with a smaller cross-section than the nominal diameter prevent the sensor running empty while measurement is in progress.
Page 23 Proline Promass I 500 PROFIBUS DP Installation Orientation Recommendation Vertical orientation A0015591 Horizontal orientation, transmitter at A0015589 Horizontal orientation, transmitter at bottom A0015590 Horizontal orientation, transmitter at side A0015592 This orientation is recommended to ensure self-draining. Applications with low process temperatures may reduce the ambient temperature. To maintain the minimum ambient temperature for the transmitter, this orientation is recommended.
Page 24 Installation Proline Promass I 500 PROFIBUS DP Static pressure It is important that cavitation does not occur, or that gases entrained in the liquids do not outgas. Cavitation is caused if the pressure drops below the vapor pressure: • In liquids that have a low boiling point (e.g. hydrocarbons, solvents, liquefied gases) •...
Page 25 Proline Promass I 500 PROFIBUS DP Installation NOTICE Danger of overheating when heating ‣ Ensure that the temperature at the lower end of the transmitter housing does not exceed 80 °C (176 °F). ‣ Ensure that sufficient convection takes place at the transmitter neck.
Page 26 Installation Proline Promass I 500 PROFIBUS DP A0030297 Eccentric clamp connection "This side up" label indicates which side is up Slope the device in accordance with the hygiene guidelines. Slope: approx. 2 % or 21 mm/m (0.24 in/feet) Line on the underside indicates the lowest point of the eccentric process connection.
Page 27 Proline Promass I 500 PROFIBUS DP Installation Zero verification and zero adjustment All measuring instruments are calibrated in accordance with state-of-the-art technology. Calibration takes place under reference conditions →  263. Therefore, a zero adjustment in the field is generally not required.
Page 28 Installation Proline Promass I 500 PROFIBUS DP 280 (11.0) 255 (10.0) 146 (5.75) 134 (5.3) 12 (0.47) 30 (1.18) A0029553  9 Weather protection cover for Proline 500; engineering unit mm (in) Cover locking: Proline 500 NOTICE Order code "Transmitter housing", option L "Cast, stainless": The covers of the transmitter housing are provided with a borehole to lock the cover.
Page 29 Proline Promass I 500 PROFIBUS DP Installation Installing the measuring instrument 6.2.1 Required tools For transmitter For mounting on a post: • Proline 500 – digital transmitter • Open-ended wrench AF 10 • Torx screwdriver TX 25 • Proline 500 transmitter...
Page 30 Installation Proline Promass I 500 PROFIBUS DP 6.2.4 Mounting the transmitter housing: Proline 500 – digital CAUTION Ambient temperature too high! Danger of electronics overheating and housing deformation. ‣ Do not exceed the permitted maximum ambient temperature. ‣ If operating outdoors: Avoid direct sunlight and exposure to weathering, particularly in warm climatic regions.
Page 31 Proline Promass I 500 PROFIBUS DP Installation 17 (0.67) 5.8 (0.23) 5.8 (0.23) 149 (5.85) A0029054  11 Engineering unit mm (in) Depends on order code for "Transmitter housing" Order code for "Transmitter housing" • Option A, aluminum, coated: L = 14 mm (0.55 in) •...
Page 32 Installation Proline Promass I 500 PROFIBUS DP 18 (0.71) 10 (0.39) 20 (0.79) 100 (3.94) A0029068  12 Engineering unit mm (in) 1. Drill the holes. 2. Insert wall plugs into the drilled holes. 3. Screw in the fixing screws slightly.
Page 33 Proline Promass I 500 PROFIBUS DP Installation 6.2.6 Turning the transmitter housing: Proline 500 To provide easier access to the connection compartment or display module, the transmitter housing can be turned. 4 mm 7 Nm (5.2 lbf ) A0043150  14 Ex housing 1.
Page 34 Installation Proline Promass I 500 PROFIBUS DP Post-installation check Is the device undamaged (visual inspection)?  Does the measuring instrument correspond to the measuring point specifications? For example: • Process temperature →  269  • Pressure (refer to the "Pressure-temperature ratings" section of the "Technical Information"...
Page 35 Proline Promass I 500 PROFIBUS DP Electrical connection Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage.
Page 36 Electrical connection Proline Promass I 500 PROFIBUS DP Ethernet-APL Shielded twisted-pair cable. Cable type A is recommended. https://www.profibus.com Ethernet-APL White Paper " Current output 0 /4 to 20 mA (excluding HART) Standard installation cable is sufficient. Pulse /frequency /switch output Standard installation cable is sufficient.
Page 37 Proline Promass I 500 PROFIBUS DP Electrical connection A0032476 Proline 500 digital transmitter Proline 500 transmitter Sensor Promass Non-hazardous area Hazardous area: Zone 2; Class I, Division 2 Hazardous area: Zone 1; Class I, Division 1 Standard cable to 500 digital transmitter →  37 Transmitter installed in the non-hazardous area or hazardous area: Zone 2;...
Page 38 Electrical connection Proline Promass I 500 PROFIBUS DP Cross-section Cable length [max.] 1.00 mm (AWG 17) 240 m (720 ft) 1.50 mm (AWG 15) 300 m (900 ft) Optionally available connecting cable Flame resistance According to DIN EN 60332-1-2 Oil resistance...
Page 39 Proline Promass I 500 PROFIBUS DP Electrical connection Cross-section Cable length [max.] Termination 2 x 2 x 0.50 mm 50 m (150 ft) 2 x 2 x 0.50 mm (AWG 20) (AWG 20) BN WT YE GN • +, – = 0.5 mm •...
Page 40 Electrical connection Proline Promass I 500 PROFIBUS DP C: Connecting cable between sensor and transmitter: Proline 500 Design 6 × 0.38 mm PVC cable with individual shielded cores and common copper shield Conductor resistance ≤ 50 Ω/km (0.015 Ω/ft) Capacitance: core/shield ≤...
Page 41 Proline Promass I 500 PROFIBUS DP Electrical connection taken into account for this device. Operation in the event of disturbance variables as per NAMUR NE21 is thus guaranteed. Where applicable, national installation regulations and guidelines must be observed during the installation! Where there are large differences in potential between the individual grounding points, only one point of the shielding is connected directly with the reference ground.
Page 42 Electrical connection Proline Promass I 500 PROFIBUS DP 1. Remove dummy plug if present. 2. If the measuring device is supplied without cable glands: Provide suitable cable gland for corresponding connecting cable. 3. If the measuring device is supplied with cable glands: Observe requirements for connecting cables →...
Page 43 Proline Promass I 500 PROFIBUS DP Electrical connection Connecting the measuring instrument: Proline 500 - digital NOTICE An incorrect connection compromises electrical safety! ‣ Only properly trained specialist staff may perform electrical connection work. ‣ Observe applicable federal/national installation codes and regulations.
Page 44 Electrical connection Proline Promass I 500 PROFIBUS DP Connecting the sensor connection housing via terminals For the device version with the order code for "Sensor connection housing": • Option A "Aluminum coated" • Option L "Cast, stainless" 10 (0.4) 3 mm...
Page 45 Proline Promass I 500 PROFIBUS DP Electrical connection Connecting the sensor connection housing via terminals For the device version with the order code for "Sensor connection housing": Option B "Stainless" 10 (0.4) 8 mm 22 mm 24 mm A0029613 1. Release the securing screw of the housing cover.
Page 46 Electrical connection Proline Promass I 500 PROFIBUS DP Connecting the sensor connection housing via the connector For the device version with the order code for "Sensor connection housing": Option C "Ultra-compact hygienic, stainless" A0029615 1. Connect the protective ground. 2. Connect the connector.
Page 47 Proline Promass I 500 PROFIBUS DP Electrical connection Connecting the connecting cable to the transmitter TX 20 TX 20 10 (0.4) 22 mm 24 mm A0029597 1. Loosen the 4 fixing screws on the housing cover. 2. Open the housing cover.
Page 48 Electrical connection Proline Promass I 500 PROFIBUS DP 7.3.2 Connecting the signal cable and the supply voltage cable A0028200 Terminal connection for supply voltage Terminal connection for signal transmission, input/output Terminal connection for signal transmission, input/output Terminal connection for connecting cable between sensor and transmitter Terminal connection for signal transmission, input/output;...
Page 49 Proline Promass I 500 PROFIBUS DP Electrical connection WARNING Housing degree of protection may be voided due to insufficient sealing of the housing. ‣ Screw in the screw without using any lubricant. NOTICE Excessive tightening torque applied to the fixing screws! Risk of damaging the plastic transmitter.
Page 50 Electrical connection Proline Promass I 500 PROFIBUS DP Connecting the measuring instrument: Proline 500 NOTICE An incorrect connection compromises electrical safety! ‣ Only properly trained specialist staff may perform electrical connection work. ‣ Observe applicable federal/national installation codes and regulations.
Page 51 Proline Promass I 500 PROFIBUS DP Electrical connection Connecting the sensor connection housing via terminals For the device version with the order code for "Housing": • Option A "Aluminum coated" • Option L "Cast, stainless" 10 (0.4) 3 mm 22 mm...
Page 52 Electrical connection Proline Promass I 500 PROFIBUS DP Connecting the sensor connection housing via terminals For the device version with the order code for "Housing": Option B "Stainless" 10 (0.4) 8 mm 22 mm 24 mm A0029613 1. Release the securing screw of the housing cover.
Page 53 Proline Promass I 500 PROFIBUS DP Electrical connection Attaching the connecting cable to the transmitter 10 (0.4) 3 mm 22 mm 24 mm A0029592 1. Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover.
Page 54 Electrical connection Proline Promass I 500 PROFIBUS DP Special connection instructions 7.6.1 Connection examples PROFIBUS DP A0028765  16 Connection example for PROFIBUS DP, non-hazardous area and Zone 2/Div. 2 Control system (e.g. PLC) Cable shield provided at one end. The cable shield must be grounded at both ends to comply with EMC requirements;...
Page 55 Proline Promass I 500 PROFIBUS DP Electrical connection 4...20 mA A0028759  18 Connection example for 4-20 mA current output (passive) Automation system with current input (e.g. PLC) Active barrier for power supply (e.g. RN221N) Analog display unit: observe maximum load...
Page 56 Electrical connection Proline Promass I 500 PROFIBUS DP Relay output A0028760  21 Connection example for relay output (passive) Automation system with relay input (e.g. PLC) Power supply Transmitter: observe input values →  258 Current input A0028915  22...
Page 57 Proline Promass I 500 PROFIBUS DP Electrical connection Hardware settings 7.7.1 Setting the device address The address must always be configured for a PROFIBUS DP/PA device. The valid address range is between 1 and 126. In a PROFIBUS DP/PA network, each address can only be assigned once.
Page 58 Electrical connection Proline Promass I 500 PROFIBUS DP Proline 500 transmitter Hardware addressing not used A0029637 Set the desired device address using the DIP switches in the connection compartment. A0029633 To switch addressing from software addressing to hardware addressing: set the DIP switch to On.
Page 59 Proline Promass I 500 PROFIBUS DP Electrical connection Proline 500 – digital transmitter A0029675 1. Open the housing cover. 2. Remove the display module. 3. Fold open the terminal cover. 4. Set DIP switch no. 3 to ON. Proline 500 transmitter ‣...
Page 60 Electrical connection Proline Promass I 500 PROFIBUS DP A0034500 1. Loosen the 4 fixing screws on the housing cover. 2. Open the housing cover. 3. Fold open the terminal cover. 4. Set DIP switch no. 2 on the I/O electronics module from OFF → ON.
Page 61 Proline Promass I 500 PROFIBUS DP Electrical connection Ensuring the degree of protection The measuring instrument fulfills all the requirements for the degree of protection IP66/67, Type 4X enclosure. To guarantee the degree of protection IP66/67, Type 4X enclosure, carry out the following steps after the electrical connection: 1.
Page 62 Operation options Proline Promass I 500 PROFIBUS DP Operation options Overview of operation options A0034513 Local operation via display module Computer with web browser or operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370...
Page 63 Proline Promass I 500 PROFIBUS DP Operation options Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: see the "Description of Device Parameters" document supplied with the device →  283...
Page 64 Operation options Proline Promass I 500 PROFIBUS DP 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (e.g. operator, maintenance etc.). Each user role contains typical tasks within the device life cycle. Menu/parameter...
Page 65 Proline Promass I 500 PROFIBUS DP Operation options Menu/parameter User role and tasks Content/meaning Expert Function- Tasks that require detailed knowledge of Contains all of the device parameters and allows direct access to these by oriented the function of the device: means of an access code.
Page 66 Operation options Proline Promass I 500 PROFIBUS DP Display area In the display area, each measured value is prefaced by certain symbol types for further description: Measured variable Measurement channel Diagnostic behavior number ↓ ↓ ↓ Example Appears only if a diagnostics event is present for this measured variable.
Page 67 Proline Promass I 500 PROFIBUS DP Operation options Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 68 Operation options Proline Promass I 500 PROFIBUS DP 8.3.2 Navigation view In the submenu In the wizard /../Operation 0091-1 /../Select medium Access stat.disp Select medium Operator Liquid Locking status Display A0013993-EN A0013995-EN Navigation view Navigation path to current position Status area Display area for navigation Operating elements →...
Page 69 Proline Promass I 500 PROFIBUS DP Operation options Setup Is displayed: • In the menu next to the "Setup" selection • At the left in the navigation path in the Setup menu Diagnosis Is displayed: • In the menu next to the "Diagnostics" selection •...
Page 70 Operation options Proline Promass I 500 PROFIBUS DP 8.3.3 Editing view Numeric editor +0.000 Xx – A0034250  25 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 71 Proline Promass I 500 PROFIBUS DP Operation options Operating key Meaning Enter key • Pressing the key briefly confirms your selection. • Pressing the key for 2 s confirms your entry. Escape key combination (press keys simultaneously) Close the editing view without accepting a change.
Page 72 Operation options Proline Promass I 500 PROFIBUS DP 8.3.4 Operating elements Operating key Meaning Minus key In menu, submenu Moves the selection bar upwards in a picklist In wizards Goes to previous parameter In the text and numeric editor Move the entry position to the left.
Page 73 Proline Promass I 500 PROFIBUS DP Operation options Calling up and closing the context menu The user is in the operational display. 1. Press the  and  keys for longer than 3 seconds.  The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 74 Operation options Proline Promass I 500 PROFIBUS DP 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 75 Proline Promass I 500 PROFIBUS DP Operation options The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 76 Operation options Proline Promass I 500 PROFIBUS DP Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN For a description of the editing view - consisting of the text editor and numeric editor - with symbols →  70, for a description of the operating elements →  72 8.3.10...
Page 77 Proline Promass I 500 PROFIBUS DP Operation options 2. Enter the access code.  The -symbol in front of the parameters disappears; all previously write- protected parameters are now re-enabled. 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation.
Page 78 Operation options Proline Promass I 500 PROFIBUS DP 8.4.2 Requirements Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have a RJ45 The operating unit must have a WLAN interface. interface. Connection Standard Ethernet cable Connection via Wireless LAN.
Page 79 Proline Promass I 500 PROFIBUS DP Operation options Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON  For information on enabling the Web server →  83...
Page 80 Operation options Proline Promass I 500 PROFIBUS DP IP address 192.168.1.XXX; for XXX all numerical sequences except: 0, 212 and 255 → e.g. 192.168.1.213 Subnet mask 255.255.255.0 Default gateway 192.168.1.212 or leave cells empty Via WLAN interface Configuring the Internet protocol of the mobile terminal NOTICE If the WLAN connection is lost during the configuration, settings made may be lost.
Page 81 Proline Promass I 500 PROFIBUS DP Operation options 2. Enter the IP address of the web server in the address line of the web browser: 192.168.1.212  The login page appears. 2 3 4 Device name: Device tag: Signal Status:...
Page 82 Operation options Proline Promass I 500 PROFIBUS DP 8.4.5 User interface A0029418 Function row Local display language Navigation area Header The following information appears in the header: • Device name • Device tag • Device status with status signal →  183 •...
Page 83 Proline Promass I 500 PROFIBUS DP Operation options Navigation area The menus, the associated submenus and parameters can be selected in the navigation area. Working area Depending on the selected function and the related submenus, various actions can be performed in this area: •...
Page 84 Operation options Proline Promass I 500 PROFIBUS DP 3. If no longer needed: Reset the modified properties of the Internet protocol (TCP/IP) →  79. Access to the operating menu via the operating tool The structure of the operating menu in the operating tools is the same as for operation via the local display.
Page 85 Proline Promass I 500 PROFIBUS DP Operation options Proline 500 – digital transmitter open press A0029163  29 Connection via service interface (CDI-RJ45) Computer with web browser (e.g. Microsoft Internet Explorer, Microsoft Edge) for accessing the integrated web server or with "FieldCare" operating tool, "DeviceCare" with COM DTM "CDI Communication TCP/IP"...
Page 86 Operation options Proline Promass I 500 PROFIBUS DP A0034569 Transmitter with integrated WLAN antenna Transmitter with external WLAN antenna LED lit constantly: WLAN reception is enabled on measuring device LED flashing: WLAN connection established between operating unit and measuring device Computer with WLAN interface and web browser (e.g.
Page 87 FieldCare Function range FDT-based (Field Device Technology) plant asset management tool from Endress+Hauser. It can configure all smart field units in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Page 88 Display area for current measured values Editing toolbar with additional functions such as save/load, event list and create documentation Navigation area with operating menu structure Work area Action area Status area 8.5.3 DeviceCare Function range Tool for connecting and configuring Endress+Hauser field devices. Endress+Hauser...
Page 89 Proline Promass I 500 PROFIBUS DP Operation options The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. Innovation brochure IN01047S Source for device description files →  90...
Page 90 System integration Proline Promass I 500 PROFIBUS DP System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.00.zz • On the title page of the manual • On the transmitter nameplate • Firmware version Diagnostics →...
Page 91 Proline Promass I 500 PROFIBUS DP System integration 9.2.1 Manufacturer-specific GSD This GSD guarantees the unrestricted functionality of the measuring device. Device-specific process parameters and functions are therefore available. Manufacturer-specific GSD ID number File name PROFIBUS DP 0x156F EH3x156F.gsd Use manufacturer-specific GSD Assignment is performed in the Ident number selector parameter via the Manufacturer option.
Page 92 System integration Proline Promass I 500 PROFIBUS DP 9.3.1 Automatic identification (factory setting) The Promass 500 PROFIBUS DP automatically recognizes the measuring device configured in the automation system (Promass 83 PROFIBUS DP) and makes the same input and output data and measured value status information available for cyclic data exchange.
Page 93 Proline Promass I 500 PROFIBUS DP System integration Using the GSD modules of the previous model In the compatibility mode, all the modules already configured in the automation system are generally supported during cyclic data transmission. However, Promass 500 does not perform further processing for the following modules, i.e.
Page 94 System integration Proline Promass I 500 PROFIBUS DP Cyclic data transmission Cyclic data transmission when using the device master file (GSD). 9.5.1 Block model The block model shows which input and output data the measuring device makes available for cyclic data exchange. Cyclic data exchange takes place with a PROFIBUS master (Class 1), e.g.
Page 95 Proline Promass I 500 PROFIBUS DP System integration AI module (Analog Input) Transmit an input variable from the measuring device to the PROFIBUS master (Class 1). The selected input variable including its status is cyclically transmitted to the PROFIBUS master (Class 1) via the AI module. The input variable is depicted in the first four bytes in the form of a floating point number as per the IEEE 754 standard.
Page 96 System integration Proline Promass I 500 PROFIBUS DP Factory setting Function block Factory setting AI 1 Mass flow AI 2 Volume flow AI 3 Corrected volume flow AI 4 Density AI 5 Mass flow AI 6 Temperature AI 7 Mass flow...
Page 97 Proline Promass I 500 PROFIBUS DP System integration SETTOT_TOTAL module The module combination consists of the SET_TOT and TOTAL functions: • SETTOT: Control the totalizers via the PROFIBUS master. • TOTAL: Transmit totalizer value incl. status to PROFIBUS master. Three Totalizer blocks are available (slot 9 to 11).
Page 98 System integration Proline Promass I 500 PROFIBUS DP Data structure Output data of SETTOT and MODETOT Byte 1 Byte 2 Control variable 1: SETTOT Control variable 2: MODETOT Input data of TOTAL Byte 1 Byte 2 Byte 3 Byte 4...
Page 99 Proline Promass I 500 PROFIBUS DP System integration The DI module cyclically transmits the discrete input value, including the status, to the PROFIBUS master (class 1). The discrete input value is depicted in the first byte. The second byte contains standardized status information pertaining to the input value.
Page 100 System integration Proline Promass I 500 PROFIBUS DP Function block Device function Values: control (meaning) DO 6 (I/O 4) Assignment of medium type DO 7 Concentration (see the following table) Only available with the Heartbeat Verification application package Only available with the Concentration application package...
Page 101 Proline Promass I 500 PROFIBUS DP System integration modules. The GSD file contains a description of the individual modules along with their individual properties. The modules are permanently assigned to the slots. When configuring the modules, it is absolutely essential to observe the sequence/arrangement of the modules. Any gaps between the configured modules must be filled with the EMPTY_MODULE.
Page 102 1001 : °C 1002 : °F 1000 : K 1003 : °R For more information on the "slot/index table", please contact the Endress+Hauser Sales Center. 9.6.4 Accessing data via PROFIBUS DP The PROFIBUS master uses the indexes 230 to 245 in slot 0 to access the address shifting data area.
Page 103 Proline Promass I 500 PROFIBUS DP System integration parameter via address shifting, the master can read out the current volume flow measured value in slot 0 and index 230. The data type (integer/float) and data access (read/write) depend on the parameter entered in the configuration area.
Page 104 Commissioning Proline Promass I 500 PROFIBUS DP Commissioning 10.1 Post-mounting and post-connection check Before commissioning the device: ‣ Make sure that the post-installation and post-connection checks have been performed successfully. • Checklist for "Post-installation" check→  34 • Checklist for "Post-connection" check→  61 10.2...
Page 105 Proline Promass I 500 PROFIBUS DP Commissioning X X X X X X X 20.50 Main menu 0104-1 Display language English Operation Setup Display language 0104-1 English Ã Deutsch Español Français Display language 0104-1 Ã English Deutsch Español Français Hauptmenü...
Page 106 Commissioning Proline Promass I 500 PROFIBUS DP Navigation "Setup" menu  Setup Device tag →  107 ‣ System units →  107 ‣ →  110 Medium selection ‣ Communication →  111 ‣ Analog inputs →  112 ‣...
Page 107 Proline Promass I 500 PROFIBUS DP Commissioning XXXXXXXXX A0029422  33 Header of the operational display with tag name Tag name Enter the tag name in the "FieldCare" operating tool →  88 Navigation "Setup" menu → Device tag Parameter overview with brief description...
Page 108 Commissioning Proline Promass I 500 PROFIBUS DP Temperature unit →  109 Pressure unit →  109 Parameter overview with brief description Parameter Description Selection Factory setting Mass flow unit Select mass flow unit. Unit choose list Country-specific: • kg/h Effect •...
Page 109 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Description Selection Factory setting Temperature unit Select temperature unit. Unit choose list Country-specific: • °C Effect • °F The selected unit applies to: • Electronic temperature parameter (6053) • Maximum value parameter (6051) •...
Page 110 Commissioning Proline Promass I 500 PROFIBUS DP 10.6.3 Selecting and setting the medium The Select medium wizard submenu contains parameters that must be configured in order to select and set the medium. Navigation "Setup" menu → Medium selection ‣ Medium selection Select medium →...
Page 111 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User entry / User interface Reference sound velocity In the Select gas type parameter, the Enter sound velocity of gas at 0 °C (32 1 to 99 999.9999 m/s Others option is selected.
Page 112 Commissioning Proline Promass I 500 PROFIBUS DP 10.6.5 Configuration of the Analog Inputs The Analog inputs submenu guides the user systematically to the individual Analog input 1 to n submenu. From here you get to the parameters of the individual analog input.
Page 113 Proline Promass I 500 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User entry Channel – Select the process variable. • Mass flow • Volume flow • Corrected volume flow • Density • Reference density • Target mass flow •...
Page 114 Commissioning Proline Promass I 500 PROFIBUS DP Navigation "Setup" menu → I/O configuration ‣ I/O configuration I/O module 1 to n terminal numbers →  114 I/O module 1 to n information →  114 →  114 I/O module 1 to n type Apply I/O configuration →...
Page 115 Proline Promass I 500 PROFIBUS DP Commissioning Signal mode →  115 0/4 mA value →  115 →  115 20 mA value Current span →  115 Failure mode →  115 Failure value →  115 Parameter overview with brief description...
Page 116 Commissioning Proline Promass I 500 PROFIBUS DP Navigation "Setup" menu → Status input 1 to n ‣ Status input 1 to n Assign status input →  116 Terminal number →  116 →  116 Active level Terminal number →...
Page 117 Proline Promass I 500 PROFIBUS DP Commissioning Assign current output 1 to n →  118 Current span →  118 →  119 0/4 mA value 20 mA value →  119 Fixed current →  119 Damping output 1 to n →...
Page 118 Commissioning Proline Promass I 500 PROFIBUS DP Parameter Prerequisite Description User interface / Factory setting Selection / User entry Assign current output 1 to n – Select process variable for • Off – current output. • Mass flow • Volume flow • Corrected volume flow •...
Page 119 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry 0/4 mA value In Current span parameter Enter 4 mA value. Signed floating-point Depends on country: (→  118), one of the number • 0 kg/h following options is selected: •...
Page 120 Commissioning Proline Promass I 500 PROFIBUS DP 10.6.10 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 121 Proline Promass I 500 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode – Define the output as a pulse, • Pulse – frequency or switch output. • Frequency • Switch Terminal number –...
Page 122 Commissioning Proline Promass I 500 PROFIBUS DP Configuring the frequency output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  122 Terminal number →  122 Signal mode →  122 Assign frequency output →...
Page 123 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Assign frequency output The Frequency option is Select process variable for • Off – selected in Operating mode frequency output. • Mass flow parameter (→  120).
Page 124 Commissioning Proline Promass I 500 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting interface / User entry Minimum frequency value The Frequency option is Enter minimum frequency. 0.0 to 10 000.0 Hz – selected in the Operating mode parameter (→  120)
Page 125 Proline Promass I 500 PROFIBUS DP Commissioning Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  125 Terminal number →  125 Signal mode →  125 Switch output function →...
Page 126 Commissioning Proline Promass I 500 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off – in the Operating mode output. • On parameter. • Diagnostic behavior •...
Page 127 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch-on value • The Switch option is Enter measured value for the Signed floating-point Depends on country: selected in the Operating switch-on point. number • 0 kg/h mode parameter.
Page 128 Commissioning Proline Promass I 500 PROFIBUS DP Switch-off value →  129 Switch-off delay →  129 →  129 Switch-on value Switch-on delay →  129 Failure mode →  129 Switch status →  130 →  130...
Page 129 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Assign limit The Limit option is selected in Select process variable for limit • Mass flow – Relay output function function. • Volume flow parameter.
Page 130 Commissioning Proline Promass I 500 PROFIBUS DP Parameter Prerequisite Description User interface / Factory setting Selection / User entry Switch status – Shows the current relay switch • Open – status. • Closed Powerless relay status – • Open – • Closed Visibility depends on order options or device settings 10.6.12 Configuring the local display...
Page 131 Proline Promass I 500 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size – are shown on the display.
Page 132 Commissioning Proline Promass I 500 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting entry Value 1 display A local display is provided. Select the measured value that • Mass flow – is shown on the local display. • Volume flow •...
Page 133 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting entry • Current output 3 0% bargraph value 1 A local display is provided. Enter 0% value for bar graph Signed floating-point Country-specific: display. number • 0 kg/h •...
Page 134 Commissioning Proline Promass I 500 PROFIBUS DP 10.6.13 Configuring the low flow cut off The Low flow cut off wizard systematically guides the user through all the parameters that must be set to configure low flow cut off. Navigation "Setup" menu → Low flow cut off ‣...
Page 135 Proline Promass I 500 PROFIBUS DP Commissioning 10.6.14 Configuring partially filled pipe detection The Partial filled pipe detection wizard guides you systematically through all parameters that have to be set for configuring the monitoring of the pipe filling. Navigation "Setup" menu → Partially filled pipe detection ‣...
Page 136 Commissioning Proline Promass I 500 PROFIBUS DP 10.7 Advanced settings The Advanced setup submenu with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu Display language English Display/operat.
Page 137 Proline Promass I 500 PROFIBUS DP Commissioning ‣ Totalizer 1 to n →  144 ‣ →  146 Display ‣ WLAN settings ‣ Viscosity ‣ Concentration ‣ Heartbeat setup ‣ Configuration backup →  151 ‣ Administration →  153 10.7.1...
Page 138 Commissioning Proline Promass I 500 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Corrected volume flow calculation – Select reference density for • Fixed reference – calculating the corrected density volume flow. • Calculated reference density •...
Page 139 Proline Promass I 500 PROFIBUS DP Commissioning ‣ Zero verification →  142 ‣ Zero adjustment →  143 Parameter overview with brief description Parameter Description Selection Installation direction Set sign of flow direction to match the direction of the arrow on •...
Page 140 Commissioning Proline Promass I 500 PROFIBUS DP If the adjustment was completed successfully, the Density adjustment factor parameter and the Density adjustment offset parameter and the values calculated for them are shown on the display. "2 point adjustment" option 1. In the Density adjustment mode parameter, select the 2 point adjustment option and confirm.
Page 141 Proline Promass I 500 PROFIBUS DP Commissioning Density adjustment factor →  141 Density adjustment offset →  141 Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Density adjustment mode – • 1 point adjustment –...
Page 142 Commissioning Proline Promass I 500 PROFIBUS DP Zero verification and zero adjustment cannot be performed if the following process conditions are present: • Gas pockets Ensure that the system has been sufficiently flushed with the medium. Repeat flushing can help to eliminate gas pockets •...
Page 143 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Description Selection / User interface Factory setting Zero point adjustment status • Busy – • Alarm • Ok Additional information Indicate whether to display additional • Hide – information. • Show Recommendation: Indicates whether an adjustment is •...
Page 144 Commissioning Proline Promass I 500 PROFIBUS DP Zero point measured →  144 Zero point standard deviation →  144 →  144 Select action Parameter overview with brief description Parameter Description Selection / User interface Factory setting Process conditions Ensure process conditions as follows.
Page 145 Proline Promass I 500 PROFIBUS DP Commissioning Unit totalizer →  145 Totalizer operation mode →  145 →  145 Control Totalizer 1 to n Failure mode →  145 Parameter overview with brief description Parameter Description Selection Factory setting Assign process variable Select process variable for totalizer.
Page 146 Commissioning Proline Promass I 500 PROFIBUS DP 10.7.4 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣...
Page 147 Proline Promass I 500 PROFIBUS DP Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size – are shown on the display.
Page 148 Commissioning Proline Promass I 500 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting entry Value 1 display A local display is provided. Select the measured value that • Mass flow – is shown on the local display. • Volume flow •...
Page 149 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User Factory setting entry • Current output 3 0% bargraph value 1 A local display is provided. Enter 0% value for bar graph Signed floating-point Country-specific: display. number • 0 kg/h •...
Page 150 Commissioning Proline Promass I 500 PROFIBUS DP Parameter Prerequisite Description Selection / User Factory setting entry Display language A local display is provided. Set display language. • English English • Deutsch (alternatively, the • Français ordered language is • Español preset in the device) •...
Page 151 Proline Promass I 500 PROFIBUS DP Commissioning Security type →  151 WLAN passphrase →  151 →  151 Assign SSID name SSID name →  151 Apply changes →  151 Parameter overview with brief description Parameter Prerequisite Description User entry / ...
Page 152 Commissioning Proline Promass I 500 PROFIBUS DP Navigation "Setup" menu → Advanced setup → Configuration backup ‣ Configuration backup Operating time →  152 Last backup →  152 →  152 Configuration management Backup state →  152 Comparison result →...
Page 153 Proline Promass I 500 PROFIBUS DP Commissioning Options Description Compare The device configuration saved in the device memory is compared with the current device configuration of the HistoROM backup. Clear backup data The backup copy of the device configuration is deleted from the memory of the device.
Page 154 Reset access code to factory settings. Character string comprising numbers, letters and special characters  For a reset code, contact your Endress+Hauser service organization. The reset code can only be entered via: • Web browser • DeviceCare, FieldCare (via CDI-RJ45 service interface) •...
Page 155 Proline Promass I 500 PROFIBUS DP Commissioning Process variable value →  156 →  157 Status input simulation Input signal level →  157 Current input 1 to n simulation →  157 Value current input 1 to n →...
Page 156 Commissioning Proline Promass I 500 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description Selection / User entry Assign simulation process variable – Select a process variable for the • Off simulation process that is activated. • Mass flow • Volume flow •...
Page 157 Proline Promass I 500 PROFIBUS DP Commissioning Parameter Prerequisite Description Selection / User entry Diagnostic event category – Select a diagnostic event category. • Sensor • Electronics • Configuration • Process Diagnostic event simulation – Select a diagnostic event to simulate • Off this event.
Page 158 Via Web browser, FieldCare, DeviceCare (via CDI-RJ45 service interface), fieldbus You can only obtain a reset code from your local Endress+Hauser service organization. The code must be calculated explicitly for every device. 1. Note down the serial number of the device.
Page 159 Proline Promass I 500 PROFIBUS DP Commissioning 10.9.2 Write protection via write protection switch Unlike parameter write protection via a user-specific access code, this allows the user to lock write access to the entire operating menu - apart from the "Contrast display"...
Page 160 Commissioning Proline Promass I 500 PROFIBUS DP NOTICE Excessive tightening torque applied to the fixing screws! Risk of damaging the plastic transmitter. ‣ Tighten the fixing screws as per the tightening torque: 2.5 Nm (1.8 lbf ft) Tighten the fixing screws.
Page 161 Proline Promass I 500 PROFIBUS DP Operation Operation 11.1 Reading off the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access authorization displayed in the Access status parameter applies →...
Page 162 Operation Proline Promass I 500 PROFIBUS DP 11.4.1 "Measured variables" submenu The Measured variables submenu contains all the parameters needed to display the current measured values for each process variable. Navigation "Diagnostics" menu → Measured values → Measured variables ‣...
Page 163 Proline Promass I 500 PROFIBUS DP Operation Parameter overview with brief description Parameter Prerequisite Description User interface Mass flow – Displays the mass flow that is currently Signed floating-point measured. number Dependency The unit is taken from: Mass flow unit parameter (→...
Page 164 Operation Proline Promass I 500 PROFIBUS DP Parameter Prerequisite Description User interface Temp. compensated kinematic For the following order code: Displays the temperature compensation Signed floating-point viscosity "Application package", option EG that is currently calculated for the number "Viscosity" kinetic viscosity.
Page 165 Proline Promass I 500 PROFIBUS DP Operation Parameter Prerequisite Description User interface Target volume flow With the following conditions: Displays the volume flow currently Signed floating-point • Order code for "Application package", measured for the target medium. number option ED "Concentration"...
Page 166 Operation Proline Promass I 500 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description Selection / User entry / User interface Assign process variable – Select process variable for totalizer. • Mass flow • Volume flow • Corrected volume flow • Target mass flow •...
Page 167 Proline Promass I 500 PROFIBUS DP Operation Navigation "Diagnostics" menu → Measured values → Input values → Current input 1 to n ‣ Current input 1 to n Measured values 1 to n →  167 Measured current 1 to n →...
Page 168 Operation Proline Promass I 500 PROFIBUS DP ‣ Pulse/frequency/switch output →  168 1 to n ‣ Relay output 1 to n →  169 Output values of current output The Value current output submenu contains all the parameters needed to display the current measured values for every current output.
Page 169 Proline Promass I 500 PROFIBUS DP Operation Parameter overview with brief description Parameter Prerequisite Description User interface Output frequency 1 to n In the Operating mode parameter, the Displays the value currently measured 0.0 to 12 500.0 Hz Frequency option is selected.
Page 170 Operation Proline Promass I 500 PROFIBUS DP Function range of "Control Totalizer " parameter Options Description Totalize The totalizer is started. Reset + hold The totaling process is stopped and the totalizer is reset to 0. Preset + hold The totaling process is stopped and the totalizer is set to its defined start value from the Preset value 1 to n parameter.
Page 171 Proline Promass I 500 PROFIBUS DP Operation • x-axis: depending on the number of channels selected displays 250 to 1000 measured values of a process variable. • y-axis: displays the approximate measured value span and constantly adapts this to the ongoing measurement.
Page 172 Operation Proline Promass I 500 PROFIBUS DP Parameter overview with brief description Parameter Prerequisite Description Selection / User entry / User interface Assign channel 1 The Extended HistoROM application Assign process variable to logging • Off package is available. channel. • Mass flow •...
Page 173 Proline Promass I 500 PROFIBUS DP Operation Parameter Prerequisite Description Selection / User entry / User interface Assign channel 4 The Extended HistoROM application Assign a process variable to logging For the picklist, see Assign package is available. channel. channel 1 parameter (→  172) ...
Page 174 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Remedial action Local display is dark, but signal output is within The cable of the display module is not plugged in...
Page 175 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting For access Fault Possible causes Remedial action Write access to parameters is not possible. Hardware write protection is enabled. Set the write protection switch on the main electronics module to the OFF position →...
Page 176 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Fault Possible causes Remedial action Operation with FieldCare or DeviceCare via Firewall of the PC or network is blocking Depending on the settings of the firewall used service interface CDI-RJ45 (port 8000) is not communication.
Page 177 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting 12.2 Diagnostic information via light emitting diodes 12.2.1 Transmitter Proline 500 – digital Different LEDs in the transmitter provide information on the device status. A0029689 Supply voltage Device status Not used...
Page 178 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Color Meaning Communication Device does not receive any Profibus data. White Device receives Profibus data. Service interface (CDI), Not connected or no connection established. Ethernet Link/Activity Yellow Connected and connection established.
Page 179 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting 12.2.2 Sensor connection housing Proline 500 – digital Various light emitting diodes (LED) on the ISEM electronics unit (intelligent sensor electronics module) in the sensor connection housing provide information about the device status.
Page 180 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display.
Page 181 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 182 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage...
Page 183 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting A0031056 Status area with status signal Diagnostic information Remedial measures with service ID In addition, diagnostic events which have occurred can be shown in the Diagnostics menu: • Via parameter →  239 •...
Page 184 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Xxxxxx/…/…/ Device name: Xxxxxxx Mass flow: kg/h 12.34 Device tag: Xxxxxxx Volume flow: 12.34 m /h ³ Status signal: Function check (C) Xxxxxx Diagnostics 1: C485 Simu... Remedy information: Deactivate... Failure (F)
Page 185 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting The user is in the Diagnostics menu. 1. Call up the desired parameter. 2. On the right in the working area, mouse over the parameter.  A tool tip with remedy information for the diagnostic event appears.
Page 186 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Coding Measuring value (hex) Byte 5 Quality Quality Substatus Limits A0032228-EN  36 Structure of the coding byte The content of the coding byte depends on the configured failure mode in the individual function block.
Page 187 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information pertaining to the electronics: diagnostic number 200 to 399 Diagnostic number 200 to 301, 303 to 399 Measured value status (fixed assignment) Diagnostic behavior Device diagnostics Quality Coding Category...
Page 188 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP 12.7 Overview of diagnostic information • The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. • All of the measured variables affected in the entire Promass instrument family are always listed under "Measured variables affected".
Page 189 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 046 Sensor limit exceeded 1. Inspect sensor 2. Check process condition Measured variable status [from the factory] Quality Good Quality substatus Maintenance demanded Coding (hex)
Page 190 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 062 Sensor connection faulty 1. Check or replace sensor electronic module (ISEM) 2. If available: Check connection cable between sensor and transmitter Measured variable status 3.
Page 191 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 082 Data storage 1. Check module connections 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 192 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 083 Memory content 1. Restart device 2. Restore HistoROM S-DAT backup (' D evice reset' parameter) Measured variable status 3. Replace HistoROM S-DAT Quality Quality substatus...
Page 193 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 140 Sensor signal asymmetrical 1. Check or replace sensor electronic module (ISEM) 2. If available: Check connection cable between sensor and transmitter Measured variable status [from the factory] 3.
Page 194 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 144 Measuring error too high 1. Check or change sensor 2. Check process conditions Measured variable status [from the factory] Quality Quality substatus Maintenance alarm...
Page 195 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting 12.7.2 Diagnostic of electronic Diagnostic information Remedy instructions Short text 201 Device failure 1. Restart device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 196 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 242 Software incompatible 1. Check software 2. Flash or change main electronics module Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 197 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 252 Modules incompatible 1. Check electronic modules 2. Check if correct modules are available (e.g. NEx, Ex) Measured variable status 3. Replace electronic modules Quality...
Page 198 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 262 Sensor electronic connection faulty 1. Check or replace connection cable between sensor electronic module (ISEM) and main electronics Measured variable status 2. Check or replace ISEM or main electronics...
Page 199 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 270 Main electronic failure Change main electronic module Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior...
Page 200 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 271 Main electronic failure 1. Restart device 2. Change main electronic module Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 201 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 272 Main electronic failure 1. Restart device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 202 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 273 Main electronic failure Change electronic Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior Alarm Influenced measured variables •...
Page 203 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 276 I/O module 1 to n faulty 1. Restart device 2. Change I/O module Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 204 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 302 Device verification active Device verification active, please wait. Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF Status signal...
Page 205 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 311 Electronic failure 1. Do not reset device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 206 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 332 Writing in HistoROM backup failed Replace user interface board Ex d/XP: replace transmitter Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 207 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 372 Sensor electronic (ISEM) faulty 1. Restart device 2. Check if failure recurs Measured variable status 3. Replace sensor electronic module (ISEM) Quality Quality substatus...
Page 208 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 373 Sensor electronic (ISEM) faulty 1. Transfer data or reset device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 209 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 375 I/O- 1 to n communication failed 1. Restart device 2. Check if failure recurs Measured variable status 3. Replace module rack inclusive electronic modules...
Page 210 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 382 Data storage 1. Insert T-DAT 2. Replace T-DAT Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior...
Page 211 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 383 Memory content 1. Restart device 2. Delete T-DAT via ' R eset device' parameter Measured variable status 3. Replace T-DAT Quality Quality substatus Maintenance alarm...
Page 212 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 387 HistoROM backup failed Contact service organization Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior Alarm Influenced measured variables •...
Page 213 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 331 Firmware update failed 1. Update firmware of device 2. Restart device Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 214 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 410 Data transfer 1. Check connection 2. Retry data transfer Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 215 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 412 Processing download Download active, please wait Measured variable status Quality Uncertain Quality substatus Initial value Coding (hex) 0x4C to 0x4F Status signal Diagnostic behavior...
Page 216 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 437 Configuration incompatible 1. Restart device 2. Contact service Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal Diagnostic behavior...
Page 217 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 438 Dataset 1. Check data set file 2. Check device configuration Measured variable status 3. Up- and download new configuration Quality Uncertain Quality substatus Maintenance demanded...
Page 218 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 442 Frequency output 1 to n 1. Check process 2. Check frequency output settings Measured variable status [from the factory] Quality Good Quality substatus Function check...
Page 219 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 453 Flow override Deactivate flow override Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF Status signal Diagnostic behavior Warning Influenced measured variables •...
Page 220 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 482 FB not Auto/Cas Set Block in AUTO mode Measured variable status Quality Good Quality substatus Coding (hex) 0x80 to 0x83 Status signal Diagnostic behavior...
Page 221 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 485 Measured variable simulation Deactivate simulation Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF Status signal Diagnostic behavior Warning Influenced measured variables •...
Page 222 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 491 Current output 1 to n simulation Deactivate simulation Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF Status signal...
Page 223 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 494 Switch output simulation 1 to n Deactivate simulation switch output Measured variable status Quality Good Quality substatus Function check Coding (hex) 0xBC to 0xBF...
Page 224 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 497 Simulation block output Deactivate simulation Measured variable status Quality Good Quality substatus Coding (hex) 0x80 to 0x83 Status signal Diagnostic behavior Warning Influenced measured variables –...
Page 225 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 529 Concentration settings faulty 1. Check concentration settings 2. Check input values e.g. pressure, temperature Measured variable status Quality Quality substatus Function check Coding (hex)
Page 226 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP 12.7.4 Diagnostic of process Diagnostic information Remedy instructions Short text 803 Current loop 1. Check wiring 2. Change I/O module Measured variable status Quality Quality substatus Process related Coding (hex) 0x28 to 0x2B...
Page 227 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 831 Sensor temperature too low Increase ambient temp. around the sensor housing Measured variable status [from the factory] Quality Uncertain Quality substatus Process related Coding (hex)
Page 228 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 832 Electronic temperature too high Reduce ambient temperature Measured variable status [from the factory] Quality Quality substatus Process related Coding (hex) 0x28 to 0x2B Status signal...
Page 229 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 833 Electronic temperature too low Increase ambient temperature Measured variable status [from the factory] Quality Quality substatus Process related Coding (hex) 0x28 to 0x2B Status signal...
Page 230 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 834 Process temperature too high Reduce process temperature Measured variable status [from the factory] Quality Uncertain Quality substatus Process related Coding (hex) 0x78 to 0x7B...
Page 231 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 835 Process temperature too low Increase process temperature Measured variable status [from the factory] Quality Uncertain Quality substatus Process related Coding (hex) 0x78 to 0x7B...
Page 232 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 842 Process limit Low flow cut off active! 1. Check low flow cut off configuration Measured variable status [from the factory] Quality Uncertain Quality substatus...
Page 233 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 882 Input signal 1. Check input configuration 2. Check external device or process conditions Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 234 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 910 Tubes not oscillating 1. Check electronic 2. Inspect sensor Measured variable status Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27 Status signal...
Page 235 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 912 Medium inhomogeneous 1. Check process cond. 2. Increase system pressure Measured variable status [from the factory] Quality Uncertain Quality substatus Process related Coding (hex)
Page 236 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 913 Medium unsuitable 1. Check process conditions 2. Check electronic modules or sensor Measured variable status [from the factory] Quality Uncertain Quality substatus Process related...
Page 237 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information Remedy instructions Short text 942 API density out of specification 1. Check process density with selected API commodity group 2. Check API related parameters Measured variable status Quality Quality substatus...
Page 238 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Diagnostic information Remedy instructions Short text 944 Monitoring failed Check process conditions for Heartbeat Monitoring Measured variable status [from the factory] Quality Quality substatus Maintenance alarm Coding (hex) 0x24 to 0x27...
Page 239 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting 12.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 240 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  37 Using the example of the local display To call up the measures to rectify a diagnostic event: •...
Page 241 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting 12.10.2 Filtering the event logbook Using the Filter options parameter you can define which category of event message is displayed in the Events list submenu. Navigation path Diagnostics → Event logbook → Filter options Filter categories •...
Page 242 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Info number Info name I1451 Monitoring on I1457 Measured error verification failed I1459 I/O module verification failed I1460 HBSI verification failed I1461 Sensor verification failed I1462 Sensor electronic module verific. failed...
Page 243 Proline Promass I 500 PROFIBUS DP Diagnostics and troubleshooting Options Description Restart device The restart resets every parameter with data stored in volatile memory (RAM) to the factory setting (e.g. measured value data). The device configuration remains unchanged. Restore S-DAT backup Restores the data that is saved on the S-DAT.
Page 244 Diagnostics and troubleshooting Proline Promass I 500 PROFIBUS DP Parameter Description User interface Factory setting Firmware version Shows the device firmware version installed. Character string in the format – xx.yy.zz Order code Shows the device order code. Character string composed of –...
Page 245 "Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: •...
Page 246 Observe the inside diameter of the measuring tube and process connection. 13.2 Measuring and test equipment Endress+Hauser offers a variety of measuring and testing equipment, such as Netilion or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services.
Page 247 • The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 248 Repair Proline Promass I 500 PROFIBUS DP 14.5 Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste.
Page 249 Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 250 Is used to stabilize the temperature of the fluids in the sensor. Water, water vapor and other non-corrosive liquids are permitted for use as fluids.  If using oil as a heating medium, please consult with Endress+Hauser. Use the order code with the product root DK8003. ...
Page 251 By using the status information, it is also a simple but effective way of checking their status and condition.  Operating Instructions BA00027S and BA00059S DeviceCare Tool to connect and configure Endress+Hauser field devices.  Innovation brochure IN01047S 15.3 System components...
Page 252 Technical data Proline Promass I 500 PROFIBUS DP Technical data 16.1 Application The measuring device is intended only for the flow measurement of liquids and gases. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media.
Page 253 Proline Promass I 500 PROFIBUS DP Technical data 16.3 Input Measured variable Direct measured variables • Mass flow • Density • Temperature • Viscosity Calculated measured variables • Volume flow • Corrected volume flow • Reference density Measuring range Measuring range for liquids Measuring range full scale values ...
Page 254 • Operating pressure to increase measurement accuracy (Endress+Hauser recommends the use of a pressure measuring device for absolute pressure, e.g. Cerabar M or Cerabar •...
Page 255 Proline Promass I 500 PROFIBUS DP Technical data Current input 0/4 to 20 mA Current input 0/4 to 20 mA (active/passive) Current span • 4 to 20 mA (active) • 0/4 to 20 mA (passive) Resolution 1 µA Voltage drop Typically: 0.6 to 2 V for 3.6 to 22 mA (passive)
Page 256 Technical data Proline Promass I 500 PROFIBUS DP 16.4 Output Output signal PROFIBUS DP Signal encoding NRZ code Data transfer 9.6 kBaud…12 MBaud Terminating resistor Integrated, can be activated via DIP switches Current output 4 to 20 mA Signal mode Can be set to: •...
Page 257 Proline Promass I 500 PROFIBUS DP Technical data Damping Configurable: 0 to 999 s Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • Density • Reference density • Temperature • Electronics temperature • Oscillation frequency 0 •...
Page 258 Technical data Proline Promass I 500 PROFIBUS DP Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • Density • Reference density • Temperature • Electronics temperature • Oscillation frequency 0 • Oscillation damping 0 • Signal asymmetry •...
Page 259 Proline Promass I 500 PROFIBUS DP Technical data Maximum switching • DC 30 V, 0.1 A capacity (passive) • AC 30 V, 0.5 A Assignable functions • Disable • On • Diagnostic behavior • Limit • Mass flow • Volume flow •...
Page 260 Technical data Proline Promass I 500 PROFIBUS DP Pulse/frequency/switch output Pulse output Fault mode Choose from: • Actual value • No pulses Frequency output Fault mode Choose from: • Actual value • 0 Hz • Definable value between: 2 to 12 500 Hz...
Page 261 Proline Promass I 500 PROFIBUS DP Technical data Low flow cut off The switch points for low flow cut off are user-selectable. Galvanic isolation The outputs are galvanically isolated: • from the power supply • from one another • from the potential equalization (PE) terminal...
Page 262 Technical data Proline Promass I 500 PROFIBUS DP switch-on current Max. 36 A (<5 ms) as per NAMUR Recommendation NE 21 Current consumption Transmitter • Max. 400 mA (24 V) • Max. 200 mA (110 V, 50/60 Hz; 230 V, 50/60 Hz) Power supply failure •...
Page 263 Proline Promass I 500 PROFIBUS DP Technical data 16.6 Performance characteristics Reference operating • Error limits based on ISO 11631 conditions • Water • +15 to +45 °C (+59 to +113 °F) • 2 to 6 bar (29 to 87 psi) •...
Page 264 Technical data Proline Promass I 500 PROFIBUS DP Zero point stability [mm] [in] [kg/h] [lb/min] 13.5 0.496 FB = Full bore Flow values Flow values as turndown parameters depending on nominal diameter. SI units 1:10 1:20 1:50 1:100 1:500 [mm]...
Page 265 Proline Promass I 500 PROFIBUS DP Technical data Pulse/frequency output o.r. = of reading Accuracy Max. ±50 ppm o.r. (over the entire ambient temperature range) Repeatability o.r. = of reading; 1 g/cm = 1 kg/l; T = medium temperature Base repeatability Design fundamentals →...
Page 266 Technical data Proline Promass I 500 PROFIBUS DP [kg/m ] [°C] [°F] -40 0 40 80 120 160 200 240 280 320 A0016614 Field density adjustment, for example at +20 °C (+68 °F) Special density calibration Temperature ±0.005 · T °C (± 0.005 · (T – 32) °F)
Page 267 Proline Promass I 500 PROFIBUS DP Technical data Calculation of the maximum measured error as a function of the flow rate Flow rate Maximum measured error in % o.r. ZeroPoint ⋅ ± BaseAccu ³ BaseAccu A0021339 A0021332 ZeroPoint ZeroPoint ⋅...
Page 268 The device is suitable for use outdoors and indoors with a relative humidity of 4 to 95 %. Operating height According to EN 61010-1 • ≤ 2 000 m (6 562 ft) • > 2 000 m (6 562 ft) with additional overvoltage protection (e.g. Endress+Hauser HAW Series) Degree of protection Transmitter •...
Page 269 Proline Promass I 500 PROFIBUS DP Technical data Internal cleaning • CIP cleaning • SIP cleaning • Cleaning with pigs Options Oil- and grease-free version for wetted parts, without declaration Order code for "Service", option HA Mechanical load Transmitter housing and sensor connection housing: •...
Page 270 Technical data Proline Promass I 500 PROFIBUS DP purge system itself or by the device, depending on which component has the lower pressure classification. The sensor housing burst pressure refers to a typical internal pressure which is reached prior to mechanical failure of the sensor housing and which was determined during type testing.
Page 271 Proline Promass I 500 PROFIBUS DP Technical data 16.10 Mechanical construction Design, dimensions For the dimensions and installation lengths of the device, see the "Technical Information" document, "Mechanical construction" section Weight All values (weight exclusive of packaging material) refer to devices with EN/DIN PN 40 flanges.
Page 272 Technical data Proline Promass I 500 PROFIBUS DP Materials Transmitter housing Housing of Proline 500 – digital transmitter Order code for "Transmitter housing": • Option A "Aluminum coated": aluminum, AlSi10Mg, coated • Option D "Polycarbonate": polycarbonate Housing of Proline 500 transmitter Order code for "Transmitter housing":...
Page 273 Proline Promass I 500 PROFIBUS DP Technical data Cable entries and adapters Material Cable gland M20 × 1.5 Plastic • Adapter for cable entry with female thread G ½" Nickel-plated brass • Adapter for cable entry with female thread NPT ½"...
Page 274 Technical data Proline Promass I 500 PROFIBUS DP Accessories Protective cover Stainless steel, 1.4404 (316L) External WLAN antenna • Antenna: ASA plastic (acrylonitrile styrene acrylate) and nickel-plated brass • Adapter: Stainless steel and nickel-plated brass • Cable: Polyethylene • Plug: Nickel-plated brass •...
Page 275 Proline Promass I 500 PROFIBUS DP Technical data Onsite operation Via display module Features: • Order code for "Display; operation", option F "4-line, illuminated, graphic display; touch control"" • Order code for "Display; operation", option G "4-line, illuminated, graphic display;...
Page 276 Technical data Proline Promass I 500 PROFIBUS DP Supported operating Operating unit Interface Additional information tools FieldCare SFE500 Notebook, PC or tablet • CDI-RJ45 service →  250 with Microsoft Windows interface system • WLAN interface • Fieldbus protocol Field Xpert SMT70/77/50 •...
Page 277 Proline Promass I 500 PROFIBUS DP Technical data HistoROM The measuring device features HistoROM data management. HistoROM data management data management comprises both the storage and import/export of key device and process data, making operation and servicing far more reliable, secure and efficient.
Page 278 The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. UKCA marking The device meets the legal requirements of the applicable UK regulations (Statutory Instruments).
Page 279 Directive a) PED/G1/x (x = category) or b) PESR/G1/x (x = category) on the sensor nameplate, Endress+Hauser confirms compliance with the "Essential Safety Requirements" a) specified in Annex I of the Pressure Equipment Directive 2014/68/EU or b) Schedule 2 of Statutory Instruments 2016 No. 1105.
Page 280 The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 281 Proline Promass I 500 PROFIBUS DP Technical data Event log: Memory volume is extended from 20 message entries (standard version) to up to 100 entries. Data logging (line recorder): • Memory capacity for up to 1000 measured values is activated.
Page 282 For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. Standard documentation Brief operating instructions...
Page 283 Proline Promass I 500 PROFIBUS DP Technical data Description of device parameters Measuring instrument Documentation code Promass 500 GP01137D Supplementary device- Safety instructions dependent documentation Safety instructions for electrical equipment for hazardous areas. Contents Documentation code Measuring device ATEX/IECEx Ex i...
Page 284 Index Proline Promass I 500 PROFIBUS DP Index 0 … 9 Connecting the measuring instrument Proline 500 ......50 3-A approval .
Page 285 Proline Promass I 500 PROFIBUS DP Index Web browser ......182 FieldCare ....... . . 87 Diagnostic message .
Page 286 Index Proline Promass I 500 PROFIBUS DP see In alarm condition Mounting requirements see Operational display Down pipe ......22 Text editor .
Page 287 Proline Promass I 500 PROFIBUS DP Index Current input 1 to n (Submenu) ... . . 166 Proline 500 connecting cable terminal assignment Current output ......116 Sensor connection housing .
Page 288 Index Proline Promass I 500 PROFIBUS DP System units ......107 Surface roughness ......274 Tag name .
Page 289 Proline Promass I 500 PROFIBUS DP Index UKCA marking ......278 Use of measuring device Borderline cases .
Page 290 *71675090* 71675090 www.addresses.endress.com...

Endress+Hauser Proline Promass I 500 Operating Instructions Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Endress+Hauser Proline Promass I 500

Summary of Contents for Endress+Hauser Proline Promass I 500
