Commissioning
Parameter
Maximum frequency value
Measuring value at minimum
frequency
Measuring value at maximum
frequency
Failure mode
Failure frequency
Invert output signal
* Visibility depends on order options or device settings
94
Prerequisite
The Frequency option is
selected in the Operating
mode parameter (→  92)
and a process variable is
selected in the Assign
frequency output parameter
(→  93).
The Frequency option is
selected in the Operating
mode parameter (→  92)
and a process variable is
selected in the Assign
frequency output parameter
(→  93).
The Frequency option is
selected in the Operating
mode parameter (→  92)
and a process variable is
selected in the Assign
frequency output parameter
(→  93).
The Frequency option is
selected in the Operating
mode parameter (→  92)
and a process variable is
selected in the Assign
frequency output parameter
(→  93).
In the Operating mode
parameter (→  92), the
Frequency option is selected,
in the Assign frequency
output parameter (→  93) a
process variable is selected,
and in the Failure mode
parameter, the Defined value
option is selected.
–
Configuring the switch output
Navigation
"Setup" menu → Pulse/frequency/switch output 1 to n
‣
Pulse/frequency/switch output
1 to n
Operating mode
Switch output function
Assign diagnostic behavior
Assign limit
Proline Prosonic Flow I 400 Modbus RS485
Description
Enter maximum frequency.
Enter measured value for
minimum frequency.
Enter measured value for
maximum frequency.
Select output behavior in the
event of a device alarm.
Enter frequency output value
in alarm condition.
Invert the output signal.
Selection / User Factory setting
entry
0.0 to 10 000.0 Hz –
Signed floating-point Depends on country
number and nominal
diameter
Signed floating-point Depends on country
number and nominal
diameter
• Actual value –
• Defined value
• 0 Hz
0.0 to 12 500.0 Hz –
• No –
• Yes
→  95
→  95
→  95
→  95
