Commissioning
Parameter
WLAN MAC address
WLAN passphrase
Assign SSID name
SSID name
Connection state
Received signal strength
Apply changes
* Visibility depends on order options or device settings
110
Prerequisite
–
The WPA2-PSK option is
selected in the Security type
parameter.
–
• The User-defined option is
selected in the Assign SSID
name parameter.
• The WLAN access point
option is selected in the
WLAN mode parameter.
–
–
–
10.5.6

Performing Heartbeat basic setup

Heartbeat setup submenu guides the user systematically through all the parameters that
can be used for the Heartbeat basic setup.
The wizard only appears if the device has the Heartbeat Verification +Monitoring
application package.
Navigation
"Setup" menu → Advanced setup → Heartbeat setup
‣
Heartbeat setup
‣
Heartbeat base settings
Proline Prosonic Flow I 400 Modbus RS485
Description
Enter MAC address of the
WLAN interface of the device.
Enter the network key (8 to 32
characters).

The network key
supplied with the device
should be changed
during commissioning
for security reasons.
Select which name will be used
for SSID: device tag or user-
defined name.
Enter the user-defined SSID
name (max. 32 characters).

The user-defined SSID
name may only be
assigned once. If the SSID
name is assigned more
than once, the devices
can interfere with one
another.
Displays the connection status. • Connected
Shows the received signal
strength.
Use changed WLAN settings.
Selection / User Factory setting
entry / User
interface
Unique 12-digit Each measuring
character string device is given an
comprising letters individual address.
and numbers
8 to 32-digit Serial number of the
character string measuring device
comprising numbers, (e.g. L100A802000)
letters and special
characters (without
spaces)
• Device tag –
• User-defined
Max. 32-digit EH_device
character string designation_last 7
comprising numbers, digits of the serial
letters and special number (e.g.
characters EH_Prosonic_Flow_4
00_A802000)
–
• Not connected
• Low –
• Medium
• High
• Cancel –
• Ok
→  111
