Technical data
Output signal
152
Status input
Maximum input values
Response time
Input signal level
Assignable functions
16.4

Output

Current output
Current output
Maximum output values
Load
Resolution
Damping
Assignable measured
variables
Pulse/frequency/switch output
Function
Version
Maximum input values
Voltage drop
Pulse output
Pulse width
Maximum pulse rate
Pulse value
Assignable measured
variables
Frequency output
Output frequency
Proline Prosonic Flow I 400 Modbus RS485
• DC 30 V
• 6 mA
Configurable: 5 to 200 ms
• Low signal (low): DC –3 to +5 V
• High signal (high): DC 12 to 30 V
• Off
• Reset totalizers 1-3 separately
• Reset all totalizers
• Flow override
Can be set as:
• 4 to 20 mA NAMUR
• 4 to 20 mA US
• 4 to 20 mA HART
• 0 to 20 mA
• DC 24 V (when idle)
• 22.5 mA
250 to 700 Ω
0.38 µA
Configurable: 0 to 999.9 s
• Volume flow
• Mass flow
• Sound velocity
• Flow velocity
• Electronics temperature

The range of options increases if the measuring device has one or more
application packages.
• With the order code for "Output; Input", option H: output 2 can be set as a pulse
or frequency output
• With the order code for "Output; Input", option I: output 2 and 3 can be set as a
pulse, frequency or switch output
Passive, open collector
• DC 30 V
• 250 mA
At 25 mA: ≤ DC 2 V
Configurable: 0.05 to 2 000 ms
10 000 Impulse/s
Configurable
• Volume flow
• Mass flow
Configurable: 0 to 12 500 Hz
