Commissioning

74
10 Commissioning
10.1

Post-mounting and post-connection check

Before commissioning the device:
‣
Make sure that the post-installation and post-connection checks have been performed
successfully.
• Checklist for "Post-mounting" check→  32
• Checklist for "Post-connection check" →  41
10.2

Switching on the measuring device

‣
Switch on the device upon successful completion of the post-mounting and post-
connection check.
 After a successful startup, the local display switches automatically from the startup
display to the operational display.
• If nothing appears on the local display or if a diagnostic message is displayed, refer
to the section on "Diagnostics and troubleshooting" →  126.
• If diagnostic information 104, 105 or 106 appears on the local display, then the
measuring point is not yet correctly mounted/configured →  135.
10.3

Setting the operating language

Factory setting: English or ordered local language
X X X X X X X X
XX
1.
2.
3.
4.
 19 Taking the example of the local display
10.4

Configuring the measuring device

The Setup menu with its guided wizards contains all the parameters needed for standard
operation.
Proline Prosonic Flow I 400 Modbus RS485
X
20.50
XX
Main menu 0104-1
Display language
English
Operation
Setup
Display language
English
Ã
Deutsch
Español
Français
Display language
à English
Deutsch
Español
Français
0104-1
0104-1
Hauptmenü 0104-1
Sprache
Deutsch
Betrieb
Setup
