Commissioning
Parameter
Pipe outer diameter
Pipe wall thickness
Liner material
Liner sound velocity
Liner thickness
Sensor type
Pipe sound velocity
Sensor coupling
Mounting type
Cable length
86
Prerequisite
The Diameter option is
selected in Pipe dimensions
parameter.
–
–
The Unknown liner material
option is selected in the Liner
material parameter.
–
–
The Unknown pipe material
option is selected in the Pipe
material parameter.
The following option is
selected in Sensor type
parameter:
• C-030-A
• C-050-A
• C-100-A
• C-100-B
• C-100-C
• C-200-A
• C-200-B
• C-200-C
• C-500-A
–
–
Proline Prosonic Flow I 400 Modbus RS485
Description
Define the outer diameter of
the pipe.
Enter the pipe wall thickness.
Select liner material.
Define the sound velocity of
liner material.
Define the thickness of liner.
Select sensor type.
Enter sound velocity of pipe
material.
Select coupling medium.
Select the number of traverses
(number of times the signal
passes through the medium).
• (1) direct option: Sensor
arrangement with 1 traverse
• (2) V-mounting option:
Sensor arrangement with 2
traverses
• (3) Z-Mounting option:
Sensor arrangement with 3
traverses
• (4) W-mounting option:
Sensor arrangement with 4
traverses
Enter length of sensor cables.
Selection / User Factory setting
entry / User
interface
0 to 20 000 mm –
Positive floating 3 mm
point number
• None –
• Cement
• Rubber
• Epoxy resin
• Unknown liner
material
800.0 to 3 800.0 m/s –
0 to 100 mm –
• C-030-A –
• C-050-A
• C-100-A
• C-100-B
• C-100-C
• C-200-A
• C-200-B
• C-200-C
• C-500-A
*
• I-100-A
800.0 to 3 800.0 m/s –
• Coupling pad –
• Coupling paste
• 1 traverse Automatic
• 2 traverses
• 3 traverses
• 4 traverses
• Automatic
0 to 200 000 mm As per order
