Connecting The Device - Endress+Hauser Proline Prosonic Flow I 400 Operating Instructions Manual

Operation options
58
Measuring device: Via CDI-RJ45 service interface
Device
Measuring device
Web server
Measuring device: via WLAN interface
Device
Measuring device
Web server
8.4.3

Connecting the device

Via service interface (CDI-RJ45)
Preparing the measuring device
Configuring the Internet protocol of the computer
The following information refers to the default Ethernet settings of the device.
IP address of the device: 192.168.1.212 (factory setting)
1. Switch on the measuring device.
2. Connect the computer to the RJ45 plug via the standard Ethernet cable .
3. If a 2nd network card is not used, close all the applications on the notebook.
 Applications requiring Internet or a network, such as e-mail, SAP applications,
Internet or Windows Explorer.
4. Close any open Internet browsers.
5. Configure the properties of the Internet protocol (TCP/IP) as defined in the table:
IP address 192.168.1.XXX; for XXX all numerical sequences except: 0, 212 and 255 → e.g.
192.168.1.213
Subnet mask 255.255.255.0
Default gateway 192.168.1.212 or leave cells empty
Via WLAN interface
Configuring the Internet protocol of the mobile terminal
NOTICE
If the WLAN connection is lost during the configuration, settings made may be lost.
‣
Make sure that the WLAN connection is not disconnected while configuring the device.
Proline Prosonic Flow I 400 Modbus RS485
CDI-RJ45 service interface
The measuring device has an RJ45 interface.
Web server must be enabled; factory setting: ON

For information on enabling the Web server →  62
WLAN interface
The measuring device has a WLAN antenna:
Transmitter with integrated WLAN antenna
Web server and WLAN must be enabled; factory setting: ON

For information on enabling the Web server →  62
Endress+Hauser
