1 Status area with status signal →  129
2 Diagnostic information →  130
3 Remedial measures with service ID
In addition, diagnostic events which have occurred can be shown in the Diagnostics
menu:
• Via parameter →  138
• Via submenu →  139
Diagnostic information
The fault can be identified using the diagnostic information. The short text helps you by
providing information about the fault. In addition, the corresponding symbol for the
diagnostic behavior is displayed in front of the diagnostic information on the local display.
Diagnostic
behavior
Example
A0013962
12.5.2

Calling up remedy information

Remedy information is provided for every diagnostic event to ensure that problems can be
rectified quickly:
• On the home page
Remedy information is displayed in a separate field below the diagnostics information.
• In the Diagnostics menu
Remedy information can be called up in the working area of the user interface.
The user is in the Diagnostics menu.
1. Call up the desired parameter.
2. On the right in the working area, mouse over the parameter.
 A tool tip with remedy information for the diagnostic event appears.
1
Diagnostic information
Diagnostic code
Diagnostic
Status signal
number
↓ ↓
842
A0013958
NAMUR 3-digit number
NE 107
Diagnosis and troubleshooting
Short text
↓
Process limit
2
3
A0008199
