Checking the installation status

The status of individual parameters can be checked in the Installation status submenu.
Navigation
"Setup" menu → Installation status
‣
Installation status

Installation status (2958)

Signal strength (2914)

Signal to noise ratio (2917)

Sound velocity (2915)

Sound velocity deviation (2986)

Parameter overview with brief description
Description
Shows the device status on installation based on the measured
values displayed.
Displays the device status after installation according to the
displayed measured values.
• Good option: No further optimization required
• Acceptable option: Measuring performance ok, optimize if
possible. You should always aim for the status Good option.
• Bad option: Optimization is required. Poor and unstable
measuring performance.
Check the following points to optimize the sensor
installation:
• Sensor distance
• Alignment of sensors
• Check the measuring point parameters in the
configuration
Displays the current signal strength (0 to 100 dB).
Assessment of the signal strength:
• < 10 dB: bad
• > 90 dB: very good
Displays the current signal to noise ratio (0 to 100 dB).
Assessment of the signal-to-noise ratio:
• < 20 dB: bad
• > 50 dB: very good
Displays the sound velocity that is currently measured.
Deviation of the measured sound velocity from the expected
sound velocity:
• < 1 %: good
• 1 to 2 %: acceptable
• > 2 %: bad
Shows the deviation of the installation sound velocity from the
measured sound velocity.
Proline Prosonic Flow I 400 Modbus RS485
User interface
• Good
• Acceptable
• Bad
Signed floating-point number
Signed floating-point number
Signed floating-point number
Signed floating-point number
→  88
→  88
→  88
→  88
→  88
