12.3.2

Calling up remedial measures

X X X X X X X X X
20.50
X
 22 Message for remedial measures
1 Diagnostic information
2 Short text
3 Service ID
4 Diagnostic behavior with diagnostic code
5 Operation time when error occurred
6 Remedial measures
1. The user is in the diagnostic message.
Press  ( symbol).
 The Diagnostic list submenu opens.
2. Select the desired diagnostic event with  or  and press  .
 The message about the remedial measures opens.
3. Press  +  simultaneously.
 The message about the remedial measures closes.
The user is in the Diagnostics menu at an entry for a diagnostics event, e.g. in the
Diagnostic list submenu or Previous diagnostics parameter.
1. Press .
 The message for the remedial measures for the selected diagnostic event opens.
2. Press  +  simultaneously.
 The message for the remedial measures closes.
12.4

Diagnostic information in the web browser

12.4.1

Diagnostic options

Any faults detected by the measuring device are displayed in the Web browser on the
home page once the user has logged on.
S
X X X X X X X X
S801
Supply voltage
XX
1.
Diagnostic list
Diagnostics 1
1
S801 Supply voltage
Diagnostics 2
Diagnostics 3
2.
Supply voltage
2
S801 0d00h02m25s
4
Increase supply voltage
6
3.
Diagnosis and troubleshooting
S
X
Menu
i
S
(ID:203) 3
5
A0029431-EN
