Proline Prosonic Flow I 400 Modbus RS485
Parameter
Operating mode
Switch output function
Assign diagnostic behavior
Assign limit
Endress+Hauser
Assign flow direction check
Assign status
Switch-on value
Switch-off value
Switch-on delay
Switch-off delay
Failure mode
Invert output signal
Parameter overview with brief description
Prerequisite
–
The Switch option is selected
in the Operating mode
parameter.
• In the Operating mode
parameter, the Switch
option is selected.
• In the Switch output
function parameter, the
Diagnostic behavior option
is selected.
• The Switch option is
selected in Operating mode
parameter.
• The Limit option is selected
in Switch output function
parameter.
Description
Define the output as a pulse,
frequency or switch output.
Select function for switch
output.
The output is switched on
(closed, conductive), if there is
a pending diagnostic event of
the assigned behavioral
category.
Select the variable to monitor
in case the specified limit value
is exceeded. If a limit value is
exceeded, the output is
switched on (conductive).
Commissioning
→  96
→  96
→  96
→  96
→  96
→  96
→  96
→  96
Selection / User Factory setting
entry
*
• Pulse –
*
• Frequency
*
• Switch
• Off –
• On
• Diagnostic
behavior
• Limit
• Flow direction
check
• Status
• Alarm –
• Alarm or warning
• Warning
• Off –
• Volume flow
• Mass flow
• Flow velocity
• Sound velocity
• Temperature
• Density
• Electronics
temperature
*
• Signal strength
• Signal to noise
*
ratio
*
• Acceptance rate
*
• Turbulence
• Totalizer 1
• Totalizer 2
• Totalizer 3
95
