10.4.10 Configuring the low flow cut off

The Low flow cut off wizard systematically guides the user through all the parameters
that must be set to configure low flow cut off.
Structure of the wizard
Off
 21
"Low flow cutoff" wizard in the "Setup" menu
Description
Select the measured value that
is shown on the local display.
Enter 0 % value for bar graph
display.
Enter 100 % value for bar
graph display.
Select the measured value that
is shown on the local display.
Select the measured value that
is shown on the local display.
Select the measured value that
is shown on the local display.
Select the measured value that
is shown on the local display.
Select the measured value that
is shown on the local display.
Assign variable
Volume flow
Mass flow
On value
Off value
End of wizard
Commissioning
Selection / User
Factory setting
entry
For the picklist, see
Value 1 display
parameter
(→  100)
Signed floating-point
Country-specific
number
Signed floating-point
number
For the picklist, see
Value 1 display
parameter
(→  100)
For the picklist, see
Value 1 display
parameter
(→  100)
For the picklist, see
Value 1 display
parameter
(→  100)
For the picklist, see
Value 1 display
parameter
(→  100)
For the picklist, see
Value 1 display
parameter
(→  100)
Flow velocity
A0043342-EN
101
