Proline Prosonic Flow I 400 Modbus RS485
Parameter
Flow velocity
Temperature
Parameter
Signal strength
Acceptance rate
Signal to noise ratio
Turbulence
Endress+Hauser
Prerequisite
–
Temperature is not entered as a fixed
value.
11.4.2

System values

The System values submenu contains all the parameters needed to display the current
measured values for every system value.
Navigation
"Diagnostics" menu → Measured values → System values
‣
System values
Signal strength
Acceptance rate
Signal to noise ratio
Turbulence
Parameter overview with brief description
Description
Displays the current signal strength (0 to 100 dB).
Assessment of the signal strength:
• < 10 dB: bad
• > 90 dB: very good
Displays the ratio of the number of ultrasonic signals accepted
for flow calculation and the total number of ultrasonic signals
emitted.
Displays the current signal to noise ratio (0 to 100 dB).
Assessment of the signal-to-noise ratio:
• < 20 dB: bad
• > 50 dB: very good
Displays the current turbulence.
11.4.3

Input values

The Input values submenu guides you systematically to the individual input values.
The submenu only appears if the device was ordered with a status input →  35..
Description
Displays the average flow velocity that
is currently calculated.
Dependency
The unit is taken from: Velocity unit
parameter
Displays the temperature that is
currently measured.
Dependency
The unit is taken from: Temperature
unit parameter
Signed floating-point number
0 to 100 %
Signed floating-point number
Signed floating-point number
Operation
User interface
Signed floating-point
number
Signed floating-point
number
→  119
→  119
→  119
→  119
User interface
