Commissioning
Parameter
Assign limit
Assign diagnostic behavior
Assign status
Switch-off value
Switch-off delay
Switch-on value
Switch-on delay
Failure mode
Switch state
Powerless relay status
98
Prerequisite
The Limit option is selected in Relay
output function parameter.
In the Relay output function
parameter, the Diagnostic behavior
option is selected.
In the Relay output function
parameter, the Digital Output option is
selected.
The Limit option is selected in the
Relay output function parameter.
In the Relay output function
parameter, the Limit option is selected.
The Limit option is selected in the
Relay output function parameter.
In the Relay output function
parameter, the Limit option is selected.
–
–
–
10.4.8

Configuring the double pulse output

The Double pulse output submenu guides the user systematically through all the
parameters that have to be set for configuring the double pulse output.
Navigation
"Setup" menu → Double pulse output
‣
Double pulse output
Signal mode
Master terminal number
Proline Prosonic Flow I 400 Modbus RS485
Description
Select process variable for limit
function.
Select diagnostic behavior for switch
output.
Select device status for switch output.
Enter measured value for the switch-off
point.
Define delay for the switch-off of status
output.
Enter measured value for the switch-on
point.
Define delay for the switch-on of status
output.
Select output behavior in the event of a
device alarm.
Select status of switch output.
User interface /
Selection / User entry
• Mass flow
• Volume flow
• Corrected volume flow
• Target mass flow
• Carrier mass flow
• Density
• Reference density
• Dynamic viscosity
• Concentration
• Kinematic viscosity
• Temp. compensated
dynamic viscosity
• Temp. compensated
kinematic viscosity
• Temperature
• Totalizer 1
• Totalizer 2
• Totalizer 3
• Oscillation damping
• Alarm
• Alarm or warning
• Warning
• Partially filled pipe
detection
• Low flow cut off
Signed floating-point
number
0.0 to 100.0 s
Signed floating-point
number
0.0 to 100.0 s
• Actual status
• Open
• Closed
• Closed
• Open
• Open
• Closed
→  99
→  99
