Commissioning
Parameter
Enter access code
Parameter
Installation direction
104
‣
WLAN settings
‣
Heartbeat setup
‣
Administration
10.5.1 Using the parameter to enter the access code
Navigation
"Setup" menu → Advanced setup
Parameter overview with brief description
Description
Enter access code to disable write protection of parameters.
10.5.2

Carrying out a sensor adjustment

The Sensor adjustment submenu contains parameters that pertain to the functionality of
the sensor.
Navigation
"Setup" menu → Advanced setup → Sensor adjustment
‣
Sensor adjustment
Installation direction
Parameter overview with brief description
Description
Select sign of flow direction.
10.5.3

Configuring the totalizer

In the "Totalizer 1 to n" submenu, you can configure the specific totalizer.
Navigation
"Setup" menu → Advanced setup → Totalizer 1 to n
‣
Totalizer 1 to n
Assign process variable 1 to n
Process variable unit 1 to n
Proline Prosonic Flow I 400 Modbus RS485
User entry
Max. 16-digit character string comprising
numbers, letters and special characters
Selection
• Forward flow
• Reverse flow
→  108
→  110
→  111
→  104
→  105
→  105
