Proline Prosonic Flow I 400 Modbus RS485
Parameter
Bus address
Baudrate
Data transfer mode
Parity
Byte order
Failure mode
1) Not a Number
Endress+Hauser
Parameter overview with brief description
Description
Enter device address.
Define data transfer speed.
Select data transfer mode.
Select parity bits.
Select byte transmission sequence.
Select measured value output behavior when a diagnostic
message occurs via Modbus communication.
1)
NaN
10.4.3

Configuring the measuring point

The "Measuring point " wizard guides you systematically through all the parameters that
must be set for the configuration of the measuring point.
Navigation
"Setup" menu → Measuring point
‣

Measuring point

Measuring point configuration (5675)
Medium (2926)
Medium temperature (3053)
Sound velocity (2929)
Viscosity (2932)
Pipe material (2927)
Commissioning
User entry / Selection
1 to 247
• 1200 BAUD
• 2400 BAUD
• 4800 BAUD
• 9600 BAUD
• 19200 BAUD
• 38400 BAUD
• 57600 BAUD
• 115200 BAUD
• 230400 BAUD
• ASCII
• RTU
Picklist ASCII option:
• 0 = Even option
• 1 = Odd option
Picklist RTU option:
• 0 = Even option
• 1 = Odd option
• 2 = None / 1 stop bit option
• 3 = None / 2 stop bits option
• 0-1-2-3
• 3-2-1-0
• 1-0-3-2
• 2-3-0-1
• NaN value
• Last valid value
→  85
→  85
→  85
→  85
→  85
→  85
83
