Summary of Contents for Endress+Hauser Proline Promass I 300
Page 1
Products Solutions Services BA01487D/06/EN/06.24-00 71674490 2024-11-01 Valid as of version 01.06.zz (Device firmware) Operating Instructions Proline Promass I 300 Coriolis flowmeter HART...
Page 2
• The manufacturer reserves the right to modify technical data without prior notice. Your Endress+Hauser sales organization will supply you with current information and updates to this manual. Endress+Hauser...
Page 3
Proline Promass I 300 HART Table of contents Table of contents About this document ....6 Mounting ......21 Document function .
Page 4
Table of contents Proline Promass I 300 HART Access to operating menu via web browser . . . 59 10.6 Simulation ......134 8.4.1...
Page 5
13.2 Measuring and test equipment ... 185 13.3 Endress+Hauser services ....185 Repair ......186 14.1 General notes .
Page 6
About this document Proline Promass I 300 HART About this document Document function These Operating Instructions contain all the information required in the various life cycle phases of the device: from product identification, incoming acceptance and storage, to installation, connection, operation and commissioning, through to troubleshooting, maintenance and disposal.
Page 7
Proline Promass I 300 HART About this document 1.2.4 Tool symbols Symbol Meaning Flat-blade screwdriver Allen key Open-ended wrench 1.2.5 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted. Preferred Procedures, processes or actions that are preferred.
Page 8
• Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. The following documentation may be available depending on the device version ordered: Document type...
Page 9
Proline Promass I 300 HART Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11
Proline Promass I 300 HART Safety instructions Device-specific IT security The device offers a range of specific functions to support protective measures on the operator' s side. These functions can be configured by the user and guarantee greater in- operation safety if used correctly. The following list provides an overview of the most...
Page 12
Safety instructions Proline Promass I 300 HART WLAN passphrase: Operation as WLAN access point A connection between an operating unit (e.g. notebook or tablet) and the device via the WLAN interface (→ 68), which can be ordered as an optional extra, is protected by the network key.
Page 13
Proline Promass I 300 HART Safety instructions The use of relevant industrial standards and guidelines that have been defined by national and international safety committees, such as IEC/ISA62443 or the IEEE, is recommended. This includes organizational security measures such as the assignment of access authorization as well as technical measures such as network segmentation.
Page 14
Product description Proline Promass I 300 HART Product description The device consists of a transmitter and a sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. Product design N ic te r e rg ö...
Page 15
• Enter the serial numbers from the nameplates in the Device Viewer (www.endress.com/deviceviewer): all the information about the device is displayed. • Enter the serial numbers from the nameplates into the Endress+Hauser Operations app or scan the DataMatrix code on the nameplate with the Endress+Hauser Operations app: all the information about the device is displayed.
Page 16
Incoming acceptance and product identification Proline Promass I 300 HART 4.2.1 Transmitter nameplate 3 4 5 Order code: Ser. no.: Ext. ord. cd.: Date: A0029192 2 Example of a transmitter nameplate Manufacturer address/certificate holder Name of the transmitter Order code...
Page 17
Proline Promass I 300 HART Incoming acceptance and product identification 4.2.2 Sensor nameplate Order code: Ser. no.: Ext. ord. cd.: Date: A0029199 3 Example of a sensor nameplate Name of the sensor Manufacturer address/certificate holder Order code Serial number (Ser. no.) Extended order code (Ext.
Page 18
Incoming acceptance and product identification Proline Promass I 300 HART 4.2.3 Symbols on the device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Please consult the documentation for the measuring instrument to discover the type of potential danger and measures to avoid it.
Page 19
Proline Promass I 300 HART Storage and transport Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 20
Storage and transport Proline Promass I 300 HART 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device. ‣...
Page 21
Proline Promass I 300 HART Mounting Mounting Mounting requirements 6.1.1 Installation position Installation point A0028772 To prevent measuring errors arising from accumulation of gas bubbles in the measuring pipe, avoid the following mounting locations in the piping: • Highest point of a pipeline.
Page 22
Mounting Proline Promass I 300 HART Ø orifice plate, pipe restriction [mm] [in] [mm] [in] ³⁄₈ 0.24 ½ 0.40 15 FB ½ FB 0.60 0.55 25 FB 1 FB 0.95 1 ½ 0.87 40 FB 1 ½ FB 1.38 1.10...
Page 23
Proline Promass I 300 HART Mounting Installation dimensions For the dimensions and installation lengths of the device, see the "Technical Information" document, "Mechanical construction" section 6.1.2 Environmental and process requirements Ambient temperature range Measuring device • –40 to +60 °C (–40 to +140 °F) •...
Page 24
Mounting Proline Promass I 300 HART NOTICE Electronics overheating on account of thermal insulation! ‣ Recommended orientation: horizontal orientation, transmitter housing pointing downwards. ‣ Do not insulate the transmitter housing . ‣ Maximum permissible temperature at the lower end of the transmitter housing: 80 °C (176 °F)
Page 25
Proline Promass I 300 HART Mounting 6.1.3 Special installation instructions Drainability When installed vertically, the measuring tube can be drained completely and protected against buildup. When the sensor is installed in a horizontal line, eccentric clamps can be used to ensure complete drainability.
Page 27
Proline Promass I 300 HART Mounting Weather protection cover 280 (11.0) 255 (10.0) 146 (5.75) 134 (5.3) 12 (0.47) 30 (1.18) A0029553 6 Engineering unit mm (in) Cover lock NOTICE Order code "Housing", option L "Cast, stainless": The covers of the transmitter housing are provided with a borehole to lock the cover.
Page 28
Mounting Proline Promass I 300 HART 6.2.2 Preparing the measuring instrument 1. Remove all remaining transport packaging. 2. Remove any protective covers or protective caps present from the sensor. 3. Remove stick-on label on the electronics compartment cover. 6.2.3 Mounting the measuring device...
Page 29
Proline Promass I 300 HART Mounting 6. Screw on the connection compartment cover. 7. Depending on the device version: Attach the securing clamp of the connection compartment cover. 4 mm 7 Nm (5.2 lbf ) A0043150 8 Ex housing 1.
Page 30
Mounting Proline Promass I 300 HART Post-installation check Is the device undamaged (visual inspection)? Does the measuring instrument correspond to the measuring point specifications? For example: • Process temperature → 209 • Pressure (refer to the "Pressure-temperature ratings" section of the "Technical Information"...
Page 31
Proline Promass I 300 HART Electrical connection Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage.
Page 32
Electrical connection Proline Promass I 300 HART Ethernet-APL Shielded twisted-pair cable. Cable type A is recommended. https://www.profibus.com Ethernet-APL White Paper " Current output 0 /4 to 20 mA (excluding HART) Standard installation cable is sufficient. Pulse /frequency /switch output Standard installation cable is sufficient.
Page 33
Proline Promass I 300 HART Electrical connection A standard cable with the following minimum requirements can be used as the connecting cable, even in the hazardous area (Zone 2, Class I, Division 2 and Zone 1, Class I, Division Standard cable 4 wires (2 pairs);...
Page 34
Electrical connection Proline Promass I 300 HART 7.2.3 Terminal assignment Transmitter: supply voltage, input/outputs The terminal assignment of the inputs and outputs depends on the individual order version of the device. The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 35
Proline Promass I 300 HART Electrical connection – – – 3 mm A0029813 1. Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Squeeze the tabs of the display module holder together. 4. Remove the display module holder.
Page 36
Electrical connection Proline Promass I 300 HART 22 mm 24 mm – A0029816 10. Connect the cable according to the terminal assignment. Signal cable terminal assignment: The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 37
Proline Promass I 300 HART Electrical connection 7.3.2 Connecting the remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra → 188.. • The remote display and operating module DKX001 is only available for the following housing versions, order code for "Housing":...
Page 38
Electrical connection Proline Promass I 300 HART Special connection instructions 7.5.1 Connection examples Current output 4 to 20 mA HART 4...20 mA A0029055 10 Connection example for 4 to 20 mA HART current output (active) Automation system with current input (e.g. PLC) Ground cable shield at one end.
Page 39
Proline Promass I 300 HART Electrical connection HART input 4...20 mA A0028763 12 Connection example for HART input with a common negative (passive) Automation system with HART output (e.g. PLC) Active barrier for power supply (e.g. RN221N) Ground cable shield at one end. The cable shield must be grounded at both ends to comply with EMC requirements;...
Page 40
Electrical connection Proline Promass I 300 HART Pulse/frequency output 12345 A0028761 15 Connection example for pulse/frequency output (passive) Automation system with pulse/frequency input (e.g. PLC with 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values → 197...
Page 41
Proline Promass I 300 HART Electrical connection A0029279 18 Connection example for double pulse output (passive) Automation system with double pulse input (e.g. PLC with a 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values → 198...
Page 42
Electrical connection Proline Promass I 300 HART Status input A0028764 21 Connection example for status input Automation system with status output (e.g. PLC) Power supply Transmitter Ensuring the degree of protection The measuring instrument fulfills all the requirements for the degree of protection IP66/67, Type 4X enclosure.
Page 43
Proline Promass I 300 HART Electrical connection If supply voltage is present: Does an indication appear on the display module? Are dummy plugs inserted in unused cable entries and have transportation plugs been replaced with dummy plugs? Endress+Hauser...
Page 44
Operation options Proline Promass I 300 HART Operation options Overview of operation options A0034513 Local operation via display module Computer with web browser or operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370 Field Xpert SMT70 Mobile handheld terminal Automation system (e.g.
Page 45
Proline Promass I 300 HART Operation options Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: see the "Description of Device Parameters" document supplied with the device...
Page 46
Operation options Proline Promass I 300 HART 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (e.g. operator, maintenance etc.). Each user role contains typical tasks within the device life cycle. Menu/parameter User role and tasks...
Page 47
Proline Promass I 300 HART Operation options Menu/parameter User role and tasks Content/meaning Expert Function- Tasks that require detailed knowledge of Contains all of the device parameters and allows direct access to these by oriented the function of the device: means of an access code.
Page 48
Operation options Proline Promass I 300 HART Display area In the display area, each measured value is prefaced by certain symbol types for further description: Measured variable Measurement channel Diagnostic behavior number ↓ ↓ ↓ Example Appears only if a diagnostics event is present for this measured variable.
Page 49
Proline Promass I 300 HART Operation options Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 50
Operation options Proline Promass I 300 HART 8.3.2 Navigation view In the submenu In the wizard /../Operation 0091-1 /../Select medium Access stat.disp Select medium Operator Liquid Locking status Display A0013993-EN A0013995-EN Navigation view Navigation path to current position Status area Display area for navigation Operating elements →...
Page 51
Proline Promass I 300 HART Operation options Setup Is displayed: • In the menu next to the "Setup" selection • At the left in the navigation path in the Setup menu Diagnosis Is displayed: • In the menu next to the "Diagnostics" selection •...
Page 52
Operation options Proline Promass I 300 HART 8.3.3 Editing view Numeric editor +0.000 Xx – A0034250 23 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 53
Proline Promass I 300 HART Operation options Operating key Meaning Enter key • Pressing the key briefly confirms your selection. • Pressing the key for 2 s confirms your entry. Escape key combination (press keys simultaneously) Close the editing view without accepting a change.
Page 54
Operation options Proline Promass I 300 HART 8.3.4 Operating elements Operating key Meaning Minus key In menu, submenu Moves the selection bar upwards in a picklist In wizards Goes to previous parameter In the text and numeric editor Move the entry position to the left.
Page 55
Proline Promass I 300 HART Operation options Calling up and closing the context menu The user is in the operational display. 1. Press the and keys for longer than 3 seconds. The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 56
Operation options Proline Promass I 300 HART 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 57
Proline Promass I 300 HART Operation options The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 58
Operation options Proline Promass I 300 HART Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN For a description of the editing view - consisting of the text editor and numeric editor - with symbols → 52, for a description of the operating elements → 54 8.3.10...
Page 59
Proline Promass I 300 HART Operation options 2. Enter the access code. The -symbol in front of the parameters disappears; all previously write- protected parameters are now re-enabled. 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation.
Page 60
Operation options Proline Promass I 300 HART 8.4.2 Requirements Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have a RJ45 The operating unit must have a WLAN interface. interface. Connection Standard Ethernet cable Connection via Wireless LAN. Screen Recommended size: ≥12"...
Page 61
Proline Promass I 300 HART Operation options Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON For information on enabling the Web server → 65...
Page 62
Operation options Proline Promass I 300 HART NOTICE Note the following to avoid a network conflict: ‣ Avoid accessing the measuring device simultaneously from the same mobile terminal via the service interface (CDI-RJ45) and the WLAN interface. ‣ Only activate one service interface (CDI-RJ45 or WLAN interface).
Page 63
Proline Promass I 300 HART Operation options 2. Enter the IP address of the web server in the address line of the web browser: 192.168.1.212 The login page appears. 2 3 4 Device name: Device tag: Signal Status: Web server language...
Page 64
Operation options Proline Promass I 300 HART 8.4.5 User interface A0029418 Function row Local display language Navigation area Header The following information appears in the header: • Device name • Device tag • Device status with status signal → 164 •...
Page 65
Proline Promass I 300 HART Operation options Working area Depending on the selected function and the related submenus, various actions can be performed in this area: • Configuring parameters • Reading measured values • Calling up help text • Starting an upload/download 8.4.6...
Page 66
Operation options Proline Promass I 300 HART Access to the operating menu via the operating tool The structure of the operating menu in the operating tools is the same as for operation via the local display. 8.5.1 Connecting the operating tool Via HART protocol This communication interface is available in device versions with a HART output.
Page 67
Proline Promass I 300 HART Operation options A0028746 27 Options for remote operation via HART protocol (passive) Control system (e.g. PLC) Transmitter power supply unit, e.g. RN221N (with communication resistor) Connection for Commubox FXA195 and Field Communicator 475 Field Communicator 475 Computer with web browser (e.g.
Page 68
Operation options Proline Promass I 300 HART Via WLAN interface The optional WLAN interface is available on the following device version: Order code for "Display; operation", option G "4-line, illuminated; touch control + WLAN" A0034570 Transmitter with integrated WLAN antenna...
Page 69
FieldCare Function range FDT-based (Field Device Technology) plant asset management tool from Endress+Hauser. It can configure all smart field units in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Page 70
Operation options Proline Promass I 300 HART Access is via: • HART protocol → 66 • CDI-RJ45 service interface → 67 • WLAN interface → 68 Typical functions: • Transmitter parameter configuration • Loading and saving of device data (upload/download) •...
Page 71
DeviceCare Function range Tool for connecting and configuring Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. Innovation brochure IN01047S Source for device description files →...
Page 72
Operation options Proline Promass I 300 HART 8.5.6 Field Communicator 475 Function scope Industrial handheld terminal from Emerson Process Management for remote configuration and measured value display via HART protocol. Source for device description files See information → 73 8.5.7...
Page 73
Proline Promass I 300 HART System integration System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.06.zz • On the title page of the manual • On the transmitter nameplate • Firmware version Diagnostics →...
Page 74
System integration Proline Promass I 300 HART Measured variables via HART protocol The following measured variables (HART device variables) are assigned to the dynamic variables at the factory: Dynamic variables Measured variables (HART device variables) Primary dynamic variable (PV) Mass flow...
Page 75
Proline Promass I 300 HART System integration Measured variables for PV (primary dynamic variable) • Measured variables which are generally available: • Mass flow • Volume flow • Corrected volume flow • Density • Reference density • Temperature • Electronics temperature •...
Page 76
System integration Proline Promass I 300 HART Measured variables for SV, TV, QV (secondary, tertiary and quaternary dynamic variable) • Measured variables which are always available: • Mass flow • Volume flow • Corrected volume flow • Density • Reference density •...
Page 77
Proline Promass I 300 HART System integration Assignment Device variables Kinematic viscosity Temp. compensated dynamic viscosity Temp. compensated kinematic viscosity Target mass flow Carrier mass flow Concentration Visible depending on the order options or device settings Endress+Hauser...
Page 78
System integration Proline Promass I 300 HART Other settings Burst mode functionality in accordance with HART 7 Specification: Navigation "Expert" menu → Communication → HART output → Burst configuration → Burst configuration 1 to n ‣ Burst configuration 1 to n Burst mode 1 to n →...
Page 79
Proline Promass I 300 HART System integration Parameter Description Selection / User entry Factory setting Burst variable 0 For HART command 9 and 33: select the • Mass flow Volume flow HART device variable or the process variable. • Volume flow • Corrected volume flow •...
Page 80
System integration Proline Promass I 300 HART Parameter Description Selection / User entry Factory setting Min. update period Enter the minimum time span between two Positive integer 1 000 ms burst commands of burst message X. Max. update period Enter the maximum time span between two...
Page 81
Proline Promass I 300 HART Commissioning Commissioning 10.1 Post-mounting and post-connection check Before commissioning the device: ‣ Make sure that the post-installation and post-connection checks have been performed successfully. • Checklist for "Post-installation" check→ 30 • Checklist for "Post-connection" check→ 42 10.2...
Page 82
Commissioning Proline Promass I 300 HART X X X X X X X 20.50 Main menu Display language English Display/operat. Setup Main menu Display/operat. Setup Diagnostic / ../Setup Medium selection XXXXXXXXX XXXXXXXXX A0032222-EN 30 Navigation to "Setup" menu using the example of the local display The number of submenus and parameters can vary depending on the device version.
Page 83
Proline Promass I 300 HART Commissioning ‣ Partially filled pipe detection → 113 ‣ Advanced setup → 114 10.4.1 Defining the tag name To enable fast identification of the measuring point within the system, you can enter a unique designation using the Device tag parameter and thus change the factory setting.
Page 84
Commissioning Proline Promass I 300 HART Corrected volume flow unit → 84 Corrected volume unit → 84 → 84 Density unit Reference density unit → 84 Density 2 unit → 85 Temperature unit → 85 →...
Page 85
Proline Promass I 300 HART Commissioning Parameter Description Selection Factory setting Density 2 unit Select second density unit. Unit choose list Country-specific: • kg/l • lb/ft³ Temperature unit Select temperature unit. Unit choose list Country-specific: • °C Effect • °F The selected unit applies to: •...
Page 86
Commissioning Proline Promass I 300 HART 10.4.3 Selecting and setting the medium The Select medium wizard submenu contains parameters that must be configured in order to select and set the medium. Navigation "Setup" menu → Medium selection ‣ Medium selection...
Page 87
Proline Promass I 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Select medium type – Use this function to select the • Liquid Liquid type of medium: "Gas" or • Gas "Liquid". Select the "Other"...
Page 88
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description Selection / User Factory setting entry / User interface Pressure value In the Pressure compensation Enter process pressure to be Positive floating- 1.01325 bar parameter, the Fixed value used for pressure correction. point number option is selected.
Page 89
Proline Promass I 300 HART Commissioning Parameter Description User interface / Selection / Factory setting User entry Apply I/O configuration Apply parameterization of the freely • No configurable I/O module. • Yes I/O alteration code Enter the code in order to change the I/O Positive integer configuration.
Page 90
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry Current span – Select current range for • 4...20 mA (4... Country-specific: process value output and 20.5 mA) • 4...20 mA NE upper/lower level for alarm •...
Page 91
Proline Promass I 300 HART Commissioning Parameter overview with brief description Parameter Description Selection / User interface / Factory setting User entry Assign status input Select function for the status input. • Off • Reset totalizer 1 • Reset totalizer 2 • Reset totalizer 3 •...
Page 92
Commissioning Proline Promass I 300 HART Parameter overview with brief description Parameter Prerequisite Description User interface / Factory setting Selection / User entry Terminal number – Shows the terminal numbers • Not used – used by the current output • 26-27 (I/O 1) module.
Page 93
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Process variable current output – Select the process variable for • Off Mass flow the current output. • Mass flow • Volume flow • Corrected volume flow •...
Page 94
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry • Oscillation damping fluctuation 0 • Oscillation damping fluctuation 1 • Exciter current 1 • HBSI • Pressure • Electronics temperature • Sensor index coil asymmetry •...
Page 95
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Failure behavior current output A process variable is selected Define output behavior in • Min. Max. in the Assign current output alarm condition. • Max.
Page 96
Commissioning Proline Promass I 300 HART 10.4.8 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 97
Proline Promass I 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode – Define the output as a pulse, • Pulse Pulse frequency or switch output. • Frequency • Switch Terminal number –...
Page 98
Commissioning Proline Promass I 300 HART Configuring the frequency output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode → 98 Terminal number → 98 Signal mode → 98 Assign frequency output →...
Page 99
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Assign frequency output The Frequency option is Select process variable for • Off selected in Operating mode frequency output. • Mass flow parameter (→ 96).
Page 100
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry • Signal asymmetry • Torsion signal asymmetry • Carrier pipe temperature • Electronics temperature • Sensor index coil asymmetry • Test point 0 • Test point 1...
Page 101
Proline Promass I 300 HART Commissioning Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode → 101 Terminal number → 101 Signal mode → 101 Switch output function →...
Page 102
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off in the Operating mode output. • On parameter. • Diagnostic behavior • Limit •...
Page 103
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Assign status • The Switch option is Select device status for switch • Partially filled pipe Partially filled pipe selected in Operating mode output. detection detection parameter.
Page 105
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description User interface / Factory setting Selection / User entry Assign limit The Limit option is selected in Select process variable for limit • Mass flow Mass flow Relay output function function. • Volume flow parameter.
Page 106
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry Failure mode – Define output behavior in • Actual status Open alarm condition. • Open • Closed Switch state – Shows the current relay switch •...
Page 107
Proline Promass I 300 HART Commissioning Parameter Description Selection / User interface / Factory setting User entry Assign pulse output Select process variable for pulse output. • Off • Mass flow • Volume flow • Corrected volume flow • Target mass flow • Carrier mass flow •...
Page 108
Commissioning Proline Promass I 300 HART Value 4 display → 111 Value 5 display → 111 → 111 Value 6 display Value 7 display → 111 Value 8 display → 111 Endress+Hauser...
Page 109
Proline Promass I 300 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 110
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Value 1 display A local display is provided. Select the measured value that • Mass flow Mass flow is shown on the local display. • Volume flow •...
Page 111
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry • Signal asymmetry • Torsion signal asymmetry • Carrier pipe temperature • Electronics temperature • Sensor index coil asymmetry • Test point 0 • Test point 1 •...
Page 112
Commissioning Proline Promass I 300 HART 10.4.12 Configuring the low flow cut off The Low flow cut off wizard systematically guides the user through all the parameters that must be set to configure low flow cut off. Navigation "Setup" menu → Low flow cut off ‣...
Page 113
Proline Promass I 300 HART Commissioning 10.4.13 Configuring partially filled pipe detection The Partial filled pipe detection wizard guides you systematically through all parameters that have to be set for configuring the monitoring of the pipe filling. Navigation "Setup" menu → Partially filled pipe detection ‣...
Page 114
Commissioning Proline Promass I 300 HART 10.5 Advanced settings The Advanced setup submenu with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu Display language English Display/operat.
Page 116
Commissioning Proline Promass I 300 HART Reference temperature (1816) → 116 Linear expansion coefficient (1817) → 116 → 116 Square expansion coefficient (1818) Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Select reference density –...
Page 117
Proline Promass I 300 HART Commissioning Navigation "Setup" menu → Advanced setup → Sensor adjustment ‣ Sensor adjustment Installation direction → 117 ‣ Density adjustment ‣ → 120 Zero verification ‣ Zero adjustment → 121 Parameter overview with brief description...
Page 118
Commissioning Proline Promass I 300 HART 3. Select the Measure density 1 option and confirm. 4. If 100% was reached in the Progress parameter on the display and the Ok option is displayed in the Execute density adjustment parameter, then confirm.
Page 119
Proline Promass I 300 HART Commissioning Density setpoint 2 → 119 Execute density adjustment → 119 → 119 Progress Density adjustment factor → 119 Density adjustment offset → 119 Parameter overview with brief description Parameter...
Page 120
Commissioning Proline Promass I 300 HART Experience shows that zero adjustment is advisable only in special cases: • To achieve maximum measurement accuracy even with low flow rates. • Under extreme process or operating conditions (e.g. very high process temperatures or very high-viscosity fluids).
Page 121
Proline Promass I 300 HART Commissioning Parameter overview with brief description Parameter Description Selection / User interface Factory setting Process conditions Ensure process conditions as follows. • Tubes are completely filled – • Process operational pressure applied • No-flow conditions (closed valves) •...
Page 122
Commissioning Proline Promass I 300 HART Root cause → 122 Reliability of measured zero point → 122 → 122 Additional information Reliability of measured zero point → 122 Zero point measured → 122 Zero point standard deviation →...
Page 123
Proline Promass I 300 HART Commissioning Navigation "Setup" menu → Advanced setup → Totalizer 1 to n ‣ Totalizer 1 to n Assign process variable → 123 Unit totalizer 1 to n → 123 → 123 Totalizer operation mode Failure mode →...
Page 124
Commissioning Proline Promass I 300 HART 10.5.5 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣ Display Format display →...
Page 125
Proline Promass I 300 HART Commissioning 0% bargraph value 7 → 129 → 129 100% bargraph value 7 Decimal places 7 → 129 Value 8 display → 129 Decimal places 8 → 130 Display language →...
Page 126
Commissioning Proline Promass I 300 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 127
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Value 1 display A local display is provided. Select the measured value that • Mass flow Mass flow is shown on the local display. • Volume flow •...
Page 128
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description Selection / User Factory setting entry • Signal asymmetry • Torsion signal asymmetry • Carrier pipe temperature • Electronics temperature • Sensor index coil asymmetry • Test point 0 • Test point 1 •...
Page 129
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Decimal places 4 A measured value is specified Select the number of decimal • x x.xx in the Value 4 display places for the display value. • x.x parameter.
Page 130
Commissioning Proline Promass I 300 HART Parameter Prerequisite Description Selection / User Factory setting entry Decimal places 8 A measured value is specified Select the number of decimal • x x.xx in the Value 8 display places for the display value. • x.x parameter.
Page 131
Proline Promass I 300 HART Commissioning Navigation "Setup" menu → Advanced setup → WLAN settings ‣ WLAN settings WLAN IP address → 131 Security type → 131 → 131 WLAN passphrase Assign SSID name → 131 SSID name →...
Page 132
Commissioning Proline Promass I 300 HART 10.5.7 Configuration management After commissioning, you can save the current device configurationor restore the previous device configuration. The device configuration is managed via the Configuration management parameter. Navigation "Setup" menu → Advanced setup → Configuration backup ‣...
Page 133
Proline Promass I 300 HART Commissioning Function scope of the "Configuration management" parameter Options Description Cancel No action is executed and the user exits the parameter. Execute backup A backup copy of the current device configuration is saved from the HistoROM backup to the memory of the device.
Page 134
Commissioning Proline Promass I 300 HART Parameter overview with brief description Parameter Description User entry Define access code Restrict write-access to parameters to protect the configuration Max. 16-digit character string comprising of the device against unintentional changes. numbers, letters and special characters Confirm access code Confirm the entered access code.
Page 135
Proline Promass I 300 HART Commissioning or closed-control loops). The simulation can be performed without a real measurement (no flow of medium through the device). Navigation "Diagnostics" menu → Simulation ‣ Simulation Assign simulation process variable → 136 Process variable value →...
Page 136
Commissioning Proline Promass I 300 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Assign simulation process variable – Select a process variable for • Off the simulation process that is • Mass flow activated. • Volume flow •...
Page 137
Proline Promass I 300 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Switch state 1 to n – Select the status of the status • Open Open output for the simulation. • Closed Relay output 1 to n simulation –...
Page 138
Commissioning Proline Promass I 300 HART 10.7.1 Write protection via access code The effects of the user-specific access code are as follows: • Via local operation, the parameters for the measuring device configuration are write- protected and their values can no longer be changed.
Page 139
Via Web browser, FieldCare, DeviceCare (via CDI-RJ45 service interface), fieldbus You can only obtain a reset code from your local Endress+Hauser service organization. The code must be calculated explicitly for every device. 1. Note down the serial number of the device.
Page 140
Commissioning Proline Promass I 300 HART A0029630 Setting the write protection (WP) switch on the main electronics module to the ON position enables hardware write protection. In the Locking status parameter, the Hardware locked option is displayed → 141. In addition, on the local display the symbol appears in front of the parameters in the header of the operational display and in the navigation view.
Page 141
Proline Promass I 300 HART Operation Operation 11.1 Reading off the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access authorization displayed in the Access status parameter applies →...
Page 142
Operation Proline Promass I 300 HART 11.4.1 "Measured variables" submenu The Measured variables submenu contains all the parameters needed to display the current measured values for each process variable. Navigation "Diagnostics" menu → Measured values → Measured variables ‣ Measured variables Mass flow →...
Page 143
Proline Promass I 300 HART Operation Parameter overview with brief description Parameter Prerequisite Description User interface Mass flow – Displays the mass flow that is currently Signed floating-point measured. number Dependency The unit is taken from: Mass flow unit parameter (→ 84) Volume flow –...
Page 144
Operation Proline Promass I 300 HART Parameter Prerequisite Description User interface Temp. compensated kinematic For the following order code: Displays the temperature compensation Signed floating-point viscosity "Application package", option EG that is currently calculated for the number "Viscosity" kinetic viscosity.
Page 145
Proline Promass I 300 HART Operation Parameter Prerequisite Description User interface Target volume flow With the following conditions: Displays the volume flow currently Signed floating-point • Order code for "Application package", measured for the target medium. number option ED "Concentration"...
Page 146
Operation Proline Promass I 300 HART Navigation "Diagnostics" menu → Measured values → Input values ‣ Input values ‣ Current input 1 to n → 146 ‣ Status input 1 to n → 146 Input values of current input The Current input 1 to n submenu contains all the parameters needed to display the current measured values for every current input.
Page 147
Proline Promass I 300 HART Operation 11.4.4 Output values The Output values submenu contains all the parameters needed to display the current measured values for every output. Navigation "Diagnostics" menu → Measured values → Output values ‣ Output values ‣...
Page 148
Operation Proline Promass I 300 HART Navigation "Diagnostics" menu → Measured values → Output values → Pulse/frequency/switch output 1 to n ‣ Pulse/frequency/switch output 1 to n → 148 Output frequency Pulse output 1 to n → 148 Switch state →...
Page 149
Proline Promass I 300 HART Operation Output values for double pulse output The Double pulse output submenu contains all the parameters needed to display the current measured values for every double pulse output. Navigation "Diagnostics" menu → Measured values → Output values → Double pulse output ‣...
Page 150
Operation Proline Promass I 300 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Control Totalizer 1 to n A process variable is selected Control totalizer value. • Totalize Totalize in the Assign process variable •...
Page 151
Proline Promass I 300 HART Operation 11.7 Displaying the measured value history The Extended HistoROM application package must be enabled in the device (order option) for the Data logging submenu to appear. This contains all the parameters for the measured value history.
Page 153
Proline Promass I 300 HART Operation Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 1 The Extended HistoROM Assign process variable to • Off application package is logging channel. • Mass flow available.
Page 154
Operation Proline Promass I 300 HART Parameter Prerequisite Description Selection / User Factory setting entry / User interface • Oscillation amplitude 1 • Signal asymmetry • Torsion signal asymmetry • Carrier pipe temperature • Electronics temperature • Sensor index coil asymmetry • Test point 0 •...
Page 155
Proline Promass I 300 HART Operation Parameter Prerequisite Description Selection / User Factory setting entry / User interface Data logging status In the Data logging Displays the measured value • Done Done parameter, the Not logging status. • Delay active overwriting option is selected.
Page 156
Operation Proline Promass I 300 HART 11.8.2 "Medium index" submenu Navigation "Expert" menu → Application → Medium index ‣ Medium index Inhomogeneous medium index (6368) → 156 Cut off inhomogeneous wet gas (6375) → 156 Cut off inhomogeneous liquid (6374) →...
Page 157
Proline Promass I 300 HART Diagnostics and troubleshooting Diagnostics and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Remedial action Local display is dark, but signal output is within The cable of the display module is not plugged in...
Page 158
Diagnostics and troubleshooting Proline Promass I 300 HART For access Fault Possible causes Remedial action Write access to parameters is not possible. Hardware write protection is enabled. Set the write protection switch on the main electronics module to the OFF position →...
Page 159
Proline Promass I 300 HART Diagnostics and troubleshooting Fault Possible causes Remedial action Operation with FieldCare or DeviceCare via Firewall of the PC or network is blocking Depending on the settings of the firewall used service interface CDI-RJ45 (port 8000) is not communication.
Page 160
Diagnostics and troubleshooting Proline Promass I 300 HART 12.2 Diagnostic information via light emitting diodes 12.2.1 Transmitter Different LEDs in the transmitter provide information on the device status. 1 2 3 4 5 A0029629 Supply voltage Device status Not used...
Page 161
Proline Promass I 300 HART Diagnostics and troubleshooting 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. Operational display in alarm condition...
Page 162
Diagnostics and troubleshooting Proline Promass I 300 HART Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 163
Proline Promass I 300 HART Diagnostics and troubleshooting 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2...
Page 164
Diagnostics and troubleshooting Proline Promass I 300 HART 12.4 Diagnostic information in the web browser 12.4.1 Diagnostic options Any faults detected by the measuring device are displayed in the Web browser on the home page once the user has logged on.
Page 165
Proline Promass I 300 HART Diagnostics and troubleshooting 12.4.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly. These measures are displayed in red along with the diagnostic event and the related diagnostic information.
Page 166
Diagnostics and troubleshooting Proline Promass I 300 HART 12.5 Diagnostic information in FieldCare or DeviceCare 12.5.1 Diagnostic options Any faults detected by the measuring device are displayed on the home page of the operating tool once the connection has been established.
Page 167
Proline Promass I 300 HART Diagnostics and troubleshooting 12.5.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: • On the home page Remedy information is displayed in a separate field below the diagnostics information.
Page 168
Diagnostics and troubleshooting Proline Promass I 300 HART 12.6 Adapting the diagnostic information 12.6.1 Adapting the diagnostic behavior Each item of diagnostic information is assigned a specific diagnostic behavior at the factory. The user can change this assignment for specific diagnostic information in the Diagnostic behavior submenu.
Page 169
Proline Promass I 300 HART Diagnostics and troubleshooting Symbol Meaning Maintenance required Maintenance is required. The measured value remains valid. A0013957 Has no effect on the condensed status. A0023076 Endress+Hauser...
Page 170
Diagnostics and troubleshooting Proline Promass I 300 HART 12.7 Overview of diagnostic information The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. In the case of some items of diagnostic information, the status signal and the diagnostic behavior can be changed.
Page 171
Proline Promass I 300 HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Module incompatible 1. Check electronic modules Alarm 2. Check if correct modules are available (e.g. NEx, Ex) 3.
Page 172
Diagnostics and troubleshooting Proline Promass I 300 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Sensor electronics 1. Restart device Warning (ISEM) faulty 2. Check if failure recurs 3. Replace sensor electronic module...
Page 173
Proline Promass I 300 HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Diagnostic event Deactivate simulation Warning simulation active Status input simulation Deactivate simulation status input Warning active...
Page 174
Diagnostics and troubleshooting Proline Promass I 300 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Process value below 1. Decrease process value Warning limit 2. Check application 3. Check sensor Partly filled pipe 1.
Page 175
Proline Promass I 300 HART Diagnostics and troubleshooting 12.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 176
Diagnostics and troubleshooting Proline Promass I 300 HART / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN 35 Using the example of the local display To call up the measures to rectify a diagnostic event: • Via local display → 163 •...
Page 177
Proline Promass I 300 HART Diagnostics and troubleshooting 12.10 Event logbook 12.10.1 Reading out the event logbook A chronological overview of the event messages that have occurred is provided in the Events list submenu. Navigation path Diagnostics menu → Event logbook submenu → Events list / ../Eventlist...
Page 178
Diagnostics and troubleshooting Proline Promass I 300 HART 12.10.3 Overview of information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnostic list. Info number Info name I1000 --------(Device ok)
Page 179
Proline Promass I 300 HART Diagnostics and troubleshooting Info number Info name I1515 Upload finished I1517 Custody transfer active I1518 Custody transfer inactive I1554 Safety sequence started I1555 Safety sequence confirmed I1556 Safety mode off I1618 I/O module 2 replaced...
Page 180
Diagnostics and troubleshooting Proline Promass I 300 HART 12.11 Resetting the measuring device The entire device configuration or some of the configuration can be reset to a defined state with the Device reset parameter (→ 134). 12.11.1 Function range of "Device reset" parameter...
Page 181
Proline Promass I 300 HART Diagnostics and troubleshooting 12.12 Device information The Device information submenu contains all parameters that display different information for device identification. Navigation "Diagnostics" menu → Device information ‣ Device information Device tag → 181 Serial number →...
Page 182
Diagnostics and troubleshooting Proline Promass I 300 HART Parameter Description User interface Factory setting Device name Shows the name of the transmitter. Promass 300/500 – The name can be found on the nameplate of the transmitter. Manufacturer Displays the manufacturer.
Page 183
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: •...
Page 184
Diagnostics and troubleshooting Proline Promass I 300 HART 12.14 Device history and compatibility The device model is documented in the order code on the nameplate of the device (e.g. 8F3BXX-XXX..XXXA1-XXXXXX). Device model Release Change compared with earlier model Compatibility with earlier model 09.2019...
Page 185
Observe the inside diameter of the measuring tube and process connection. 13.2 Measuring and test equipment Endress+Hauser offers a variety of measuring and testing equipment, such as Netilion or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services.
Page 186
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 187
Proline Promass I 300 HART Repair 14.5 Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste.
Page 188
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 189
Is used to stabilize the temperature of the fluids in the sensor. Water, water vapor and other non-corrosive liquids are permitted for use as fluids. If using oil as a heating medium, please consult with Endress+Hauser. Use the order code with the product root DK8003. ...
Page 190
Via the Internet: https://portal.endress.com/webapp/applicator Netilion lloT ecosystem: Unlock knowledge With the Netilion IIoT ecosystem,Endress+Hauser allows you to optimize your plant performance, digitize workflows, share knowledge, and enhance collaboration. Drawing upon decades of experience in process automation, Endress+Hauser offers the process industry an IIoT ecosystem designed to effortlessly extract insights from data.
Page 191
Proline Promass I 300 HART Technical data Technical data 16.1 Application The measuring device is intended only for the flow measurement of liquids and gases. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media.
Page 192
Technical data Proline Promass I 300 HART 16.3 Input Measured variable Direct measured variables • Mass flow • Density • Temperature • Viscosity Calculated measured variables • Volume flow • Corrected volume flow • Reference density Measuring range Measuring range for liquids Measuring range full scale values ...
Page 193
• Operating pressure to increase measurement accuracy (Endress+Hauser recommends the use of a pressure measuring device for absolute pressure, e.g. Cerabar M or Cerabar •...
Page 194
Technical data Proline Promass I 300 HART Current input The measured values are written from the automation system to the measuring device via the current input → 194. Current input 0/4 to 20 mA Current input 0/4 to 20 mA (active/passive) Current span •...
Page 195
Proline Promass I 300 HART Technical data 16.4 Output Output signal Current output 4 to 20 mA HART Order code "Output; input 1" (20): Option BA: current output 4 to 20 mA HART Signal mode Can be set to: • Active •...
Page 196
Technical data Proline Promass I 300 HART Damping Configurable: 0 to 999.9 s Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • Density • Reference density • Temperature • Electronics temperature • Oscillation frequency 0 •...
Page 197
Proline Promass I 300 HART Technical data Maximum output values 22.5 mA Maximum input voltage DC 30 V Load 0 to 700 Ω Resolution 0.38 µA Damping Configurable: 0 to 999 s Assignable measured • Mass flow variables • Volume flow •...
Page 198
Technical data Proline Promass I 300 HART Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • Density • Reference density • Temperature • Electronics temperature • Oscillation frequency 0 • Oscillation damping 0 • Signal asymmetry •...
Page 199
Proline Promass I 300 HART Technical data Pulse/pause ratio Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • Density • Reference density • Temperature The range of options increases if the measuring device has one or more application packages.
Page 200
Technical data Proline Promass I 300 HART Current output 0/4 to 20 mA 4 to 20 mA Failure mode Choose from: • 4 to 20 mA in accordance with NAMUR recommendation NE 43 • 4 to 20 mA in accordance with US •...
Page 201
Proline Promass I 300 HART Technical data Interface/protocol • Via digital communication: HART protocol • Via service interface • CDI-RJ45 service interface • WLAN interface Plain text display With information on cause and remedial measures Web browser Plain text display...
Page 202
Technical data Proline Promass I 300 HART Order code Terminal voltage Frequency range "Power supply" DC 24 V ±20% – Option I AC 100 to 240 V –15…+10% 50/60 Hz Power consumption Transmitter Max. 10 W (active power) switch-on current Max.
Page 203
Proline Promass I 300 HART Technical data 16.6 Performance characteristics Reference operating • Error limits based on ISO 11631 conditions • Water • +15 to +45 °C (+59 to +113 °F) • 2 to 6 bar (29 to 87 psi) •...
Page 204
Technical data Proline Promass I 300 HART Zero point stability [mm] [in] [kg/h] [lb/min] 13.5 0.496 FB = Full bore Flow values Flow values as turndown parameters depending on nominal diameter. SI units 1:10 1:20 1:50 1:100 1:500 [mm] [kg/h]...
Page 205
Proline Promass I 300 HART Technical data Pulse/frequency output o.r. = of reading Accuracy Max. ±50 ppm o.r. (over the entire ambient temperature range) Repeatability o.r. = of reading; 1 g/cm = 1 kg/l; T = medium temperature Base repeatability Design fundamentals →...
Page 206
Technical data Proline Promass I 300 HART [kg/m ] [°C] [°F] -40 0 40 80 120 160 200 240 280 320 A0016614 Field density adjustment, for example at +20 °C (+68 °F) Special density calibration Temperature ±0.005 · T °C (± 0.005 · (T – 32) °F)
Page 207
Proline Promass I 300 HART Technical data Calculation of the maximum measured error as a function of the flow rate Flow rate Maximum measured error in % o.r. ZeroPoint ⋅ ± BaseAccu ³ BaseAccu A0021339 A0021332 ZeroPoint ZeroPoint ⋅ ⋅...
Page 208
The device is suitable for use outdoors and indoors with a relative humidity of 4 to 95 %. Operating height According to EN 61010-1 • ≤ 2 000 m (6 562 ft) • > 2 000 m (6 562 ft) with additional overvoltage protection (e.g. Endress+Hauser HAW Series) Degree of protection Transmitter •...
Page 209
Proline Promass I 300 HART Technical data Electromagnetic • As per IEC/EN 61326 and NAMUR Recommendation 21 (NE 21) compatibility (EMC) • As per IEC/EN 61000-6-2 and IEC/EN 61000-6-4 Details are provided in the Declaration of Conformity. This unit is not intended for use in residential environments and cannot guarantee adequate protection of the radio reception in such environments.
Page 210
Technical data Proline Promass I 300 HART Sensor housing burst pressure [mm] [in] [bar] [psi] 50 FB 2 FB 6 670 6 670 FB = Full bore For information on the dimensions: see the "Mechanical construction" section of the "Technical Information" document...
Page 211
Proline Promass I 300 HART Technical data Weight in SI units Weight [kg] [mm] 15 FB 25 FB 40 FB 50 FB FB = Full bore Weight in US units Weight [lbs] [in] ½ ½ FB 1 FB 1½ 1½ FB...
Page 212
Technical data Proline Promass I 300 HART Cable entries/cable glands A0020640 37 Possible cable entries/cable glands Female thread M20 × 1.5 Cable gland M20 × 1.5 Adapter for cable entry with female thread G ½" or NPT ½" Order code for "Housing", option A "Aluminum, coated"...
Page 213
Proline Promass I 300 HART Technical data Process connections • Flanges according to EN 1092-1 (DIN 2501) / according to ASME B16.5/ according to JIS: • Stainless steel 1.4301 (304) • Wetted parts: Grade 2 titanium • All other process connections: Grade 2 titanium Available process connections→...
Page 214
Technical data Proline Promass I 300 HART 16.11 Operability Languages Can be operated in the following languages: • Via local operation English, German, French, Spanish, Italian, Dutch, Portuguese, Polish, Russian, Turkish, Chinese, Japanese, Korean, Vietnamese, Czech, Swedish • Via web browser...
Page 215
Proline Promass I 300 HART Technical data Via remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra → 188.. • The remote display and operating module DKX001 is only available for the following housing versions, order code for "Housing":...
Page 216
Technical data Proline Promass I 300 HART Remote operation → 66 Service interface → 67 Supported operating tools Different operating tools can be used for local or remote access to the measuring device. Depending on the operating tool used, access is possible with different operating units and via a variety of interfaces.
Page 217
Proline Promass I 300 HART Technical data Supported functions Data exchange between the operating unit (such as a notebook, for example,) and measuring instrument: • Upload the configuration from the measuring instrument (XML format, configuration backup) • Save the configuration to the measuring instrument (XML format, restore configuration) •...
Page 218
The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. UKCA marking The device meets the legal requirements of the applicable UK regulations (Statutory Instruments).
Page 219
Directive a) PED/G1/x (x = category) or b) PESR/G1/x (x = category) on the sensor nameplate, Endress+Hauser confirms compliance with the "Essential Safety Requirements" a) specified in Annex I of the Pressure Equipment Directive 2014/68/EU or b) Schedule 2 of Statutory Instruments 2016 No. 1105.
Page 220
Technical data Proline Promass I 300 HART Radio approval The measuring device has radio approval. For detailed information on the radio approval, see the Special Documentation → 224 Additional certification CRN approval Some device versions have CRN approval. A CRN-approved process connection with a CSA approval must be ordered for a CRN-approved device.
Page 221
Technical data The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 222
Technical data Proline Promass I 300 HART The measured density is converted to the concentration of a substance of a binary mixture using the "Concentration" application package: • Choice of predefined fluids (e.g. various sugar solutions, acids, alkalis, salts, ethanol etc.).
Page 223
For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. Standard documentation Brief Operating Instructions...
Page 224
Technical data Proline Promass I 300 HART Contents Documentation code EAC Ex nA XA01657D JPN Ex d XA01778D Remote display and operating module DKX001 Contents Documentation code ATEX/IECEx Ex i XA01494D ATEX/IECEx Ex ec XA01498D cCSAus IS XA01499D cCSAus Ex nA...
Page 225
Proline Promass I 300 HART Index Index 0 … 9 Connecting the supply voltage cables ... . . 34 Connection 3-A approval ......219 see Electrical connection Connection cable .
Page 226
Index Proline Promass I 300 HART Display Field of application see Local display Residual risks ......10 Display and operating module DKX001 .
Page 227
Proline Promass I 300 HART Index Inspection For specific settings ..... . 114 Connection ......42 Mounting .
Page 228
Index Proline Promass I 300 HART Burst configuration 1 to n (Submenu) ..78 Pressure-temperature ratings ....209 Configuration backup (Submenu) .
Page 229
Proline Promass I 300 HART Index Simulation ......134 System units ......83 Status input .
Page 230
Index Proline Promass I 300 HART UKCA marking ......218 Use of measuring device Borderline cases .
Need help?
Do you have a question about the Proline Promass I 300 and is the answer not in the manual?
Questions and answers
