Atm Configuration Examples; Ipoa Configuration Example - 3Com MSR 50 Series Configuration Manual

140 C 5: ATM C
HAPTER
ATM Configuration
Examples
IPoA Configuration
Example
ONFIGURATION
To do...
Send OAM cells on the specified
PVC on the interface to test
connectivity of the link
depending on whether response
is returned before the specified
timeout time.
Shut down the current physical
ATM interface
n
In the following examples, the network device, the digital subscriber line access
multiplexer (DSLAM) and its configuration command sequence are MA 5100
multi-business access device and the corresponding command sequence under its
configuration environment. ADSL router is configured according to the actual
selected devices in the actual networking environment. For complete details about
configuration commands, please refer to the corresponding command manuals.
With regard to practical networking, the network devices might be different from
the assumed devices in terms of networking capacity and configuration command
format. This situation is subject to exist without notice.
Network requirements
As shown in Figure
intercommunication. The requirements are:
The IP addresses of their ATM interfaces of the three routers are 202.38.160.1/24,
202.38.160.2/24 and 202.38.160.3/24 respectively;
In ATM network, the VPI/VCI of router A is 0/40 and 0/41, connecting to router B
and router C respectively. The VPI/VCI of router B is 0/50 and 0/51, connecting to
router A and C respectively. The VPI/VCI of router C is 0/60 and 0/61, connected
with router A and B respectively;
All the PVCs on ATM interfaces of the three routers work in IPoA application
mode.
Use the command...
oamping interface atm
interface-number pvc { pvc-name
| vpi/vci } [ number timeout ]
shutdown
7, router A, B and C are connected to ATM network for
Remarks
Available in ATM
interface view
Available in ATM
interface view
