Configuring Svc Application Of X.25 Over Fr; Configuring Pvc Application Of X.25 Over Fr - 3Com MSR 50 Series Configuration Manual

Configuring SVC
Application of X.25 over
Configuring PVC
Application of X.25 over
X.25 over FR is an extension to X.25 switching, so you need enable X.25 switch
first.
FR
To configure SVC application of X.25 over FR, use the following commands:
To do...
Enter system view
Enable X.25 switching
Enter interface view
Specify the link layer protocol
as FR
Specify the FR interface type
Configure an FR DLCI and
enter its view
Configure the FR DLCI as
Annex G DLCI
Configure the SVC route
Configure the X.25 over FR
SVC route
X.25 over FR is an extension to X.25 switching, so you need enable X.25 switch
first.
FR
To configure SVC application of X.25 over FR, use the following commands:
To do...
Enter system view
Enable X.25 switching
Create an X.25 template
Specify the VC range
Use the command...
system-view
x25 switching
interface interface-type
interface-number
link-protocol fr
[ nonstandard | ietf ]
fr interface-type { dce | dte |
nni }
fr dlci dlci-number
annexg { dce | dte }
x25 switch svc [ -number ]
x.121-address [ sub-dest
destination-address |
sub-source source-address ]
* interface interface-type
interface-number
x25 switch svc [ -number ]
x.121-address [ sub-dest
destination-address |
sub-source source-address ]
* interface interface-type
interface-number dlci
dlci-number
Use the command...
system-view
x25 switching
x25 template { name }
x25 vc-range { bi-channel
ltc htc [ out-channel loc hoc ]
| in-channel lic hic
[ bi-channel ltc htc ]
[ out-channel loc hoc ] |
out-channel loc hoc }
Configuring X.25 over FR
Remarks
-
Required
Not enabled by default
-
Required
PPP by default
Required
DTE by default
Required
Required
Required
After receiving a packet on
the SVC, the packet is
forwarded via a local
interface. Use this command
to configure the local forward
interface.
Required
Remarks
-
Required
Not enabled by default
Required
Required
311
