Overview

Configuring PPPoFR

Displaying and
Maintaining PPPoFR
PPP FR
O
This section covers these topics:
"Overview" on page 235
■
"Configuring PPPoFR" on page 263
■
"Displaying and Maintaining PPPoFR" on page 263
■
"PPPoFR Configuration Example" on page 264
■
PPP over frame relay (PPPoFR) enables routers to establish end-to-end PPP sessions
on a frame relay network, allowing frame relay stations to use PPP features such as
LCP, NCP, authentication, and MP fragmentation.
Follow these steps to configure PPPoFR:
To do...
Enter system view
Create a virtual template
interface and the virtual
template interface view
Assign IP address
Return to system view
Enter corresponding frame
relay interface
Configure interface
encapsulation protocol to
frame relay
Configure a frame relay DLCI fr dlci dlci-number
Map frame relay DLCI to PPP
n
As for the next hop and the outbound interface, only the former is required when
you configure a static route on a virtual-template interface. If you want to specify
the outbound interface as well, make sure the physical interface bound to the
virtual-template interface is valid.
To do...
Display PPPoFR MAP and
status
Use the command...
system-view
interface virtual-template
interface-number
ip address ip-address ip-mask
quit
interface interface-type
interface-number
link-protocol fr
fr map ppp dlci-number interface
virtual-template interface-number
Use the command...
display fr map-info pppofr [ interface
interface-type interface-number ]
Remarks
-
-
Required
Required
-
Required
Required (optional for
DTE side)
Required
Remarks
Available in any
view
