voltage lower voltage(228V) 90%( below 205, 2V), the time lasts 2s or
more, the SVG will stop working automatically, but within 205, 2V, the
SVG still working.
If "Disable" is selected, the SVG will stop working when the voltage
reaches the lower limit (228V).
Note: ① The voltage lower the compensation performance will be
worse. ② Please contact engineer of Sinexcel before changing this
parameter.
It is for maximum speed adjusted of fan.
1 is 100% speed, 0.9 is 90% speed.
Generally, this setting is not changed, but when the customer feels
Fan gear
that the machine is noisy, you can contact the engineer of Sinexcel to
adjust it.
When the Grid THDU of L1/L2/L3 phase shown in the HMI is different
with the Grid THDU of L1/L2/L3 phase measured by the power quality
detector.
L1/L2/L3_gri
d_THDU Coefficient = Actual Grid THDU of L1/L2/L3 phase value on power
quality detector / Grid THDU of L1/L2/L3 phase value on HMI.
_config.
For factory HMI calibration, customer is forbidden to change it.
Only when the customer has to replace a 4.3inch HMI, then the
customer may have to re-calibrate these settings by themselves if they
do not keep a record of the calibration data before.
L1/L2/L3_gri
Eg. If the external power quality analyzer shows the grid THDI is 10%,
d_THDI
while Sinexcel HMI shows 12%, you can change the setting of
_config.
"L1/L2/L3_grid_THDI_config." to 10/12=0.83 to calibrate Sinexcel
HMI.
When the load THDI of L1/L2/L3 phase shown in the HMI is different
with the load THDI of L1/L2/L3 phase measured by the power quality
detector.
L1/L2/L3_loa
d_THDI
Coefficient = Actual load THDI of L1/L2/L3 phase value on power
_config.
quality detector / Load THDI of L1/L2/L3 phase value on HMI.
Product
Use to choose the correspond product for the screen.
model
Clear all alarm history record
Clear alarm
Automatically choose the correspond product for the screen.
Product
model adapt
31
0.5~1 1.0
>0 1.0
>0 1.0
>0 1.0
SVG
According
SVG to actual
condition
ASVG
According
Clear to actual
condition
Disable
Disable
Enable
Value
Value
Value
Value
N/A
N/A
N/A
