ACQUIRE PARAMETERS OF DEVICE (HARMONIC COMPENSATION PARAMETERS)

Function Code = 03, 04
Register start address = 0x2A00
Register Address
Initialization
0x2A00
0x2A02
0x2A04
0x2A06
0x2A08
0x2A0A
0x2A0C
0x2A0E
0x2A10
0x2A12
0x2A14
0x2A16
0x2A18
0x2A1A
0x2A1C
0x2A1E
0x2A20
0x2A22
0x2A24
0x2A26
0x2A28
0x2A2A
0x2A2C
0x2A2E
0x2A30
0x2A32
0x2A34
Table A- 14 Acquire Parameters of Device (harmonic Compensation Parameters)
Byte Name
4 2nd harmonic compensation degree
4 3rd harmonic compensation degree
4 4th harmonic compensation degree
4 5th harmonic compensation degree
4 6th harmonic compensation degree
4 7th harmonic compensation degree
4 8th harmonic compensation degree
4 9th harmonic compensation degree
4 10th harmonic compensation degree
4 11th harmonic compensation degree
4 12th harmonic compensation degree
4 13th harmonic compensation degree
4 14th harmonic compensation degree
4 15th harmonic compensation degree
4 16th harmonic compensation degree
4 17th harmonic compensation degree
4 18th harmonic compensation degree
4 19th harmonic compensation degree
4 20th harmonic compensation degree
4 21st harmonic compensation degree
4 22nd harmonic compensation degree
4 23rd harmonic compensation degree
4 24th harmonic compensation degree
4 25th harmonic compensation degree
4 26th harmonic compensation degree
4 27th harmonic compensation degree
4 28th harmonic compensation degree
71
Remark
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
[0, 110]
Default: 0
