EPO_A
GND
EPO_A
GND
CT_A
GND_A
CT_B
GND_B
CT_C
GND_C
LAN (optional)
IN1 (optional)
IN2 (optional)
OUT1 (optional)
OUT2 (optional)
N
N
L3
Power terminal
L2
L1
PE
To parallel the EPO signal of each module
To parallel the EPO signal of each module
To parallel the EPO signal of each module
To parallel the EPO signal of each module
Connected to S1 of phase L1 CT
Connected to S2 of phase L1 CT
Connected to S1 of phase L2 CT
Connected to S2 of phase L2 CT
Connected to S1 of phase L3 CT
Connected to S2 of phase L3 CT
Dry contact board terminals (optional), including 1 Ethernet
port, 2 input dry contact and 2 output dry contacts, the detailed
introduction please refer to Appendix Ⅲ.
Power cable connection
The grounding terminal of a device is an important
component that ensures electrical safety.
