READ THE WAVEFORM DATA OF THE DEVICE(WAVEFORM)

Function Code = 03, 04
Register Start Address = 0x0500
A complete waveform consists of 128 points. A byte represents the value of a point. 128 points are needed to
draw a complete waveform. Data is transferred from low to high, where the first byte represents the first point,
and so on.
Register Address
0x0500
0x0540
0x0580
0x05C0
0x0600
0x0640
0x0680
0x06C0
0x0700
0x0740
0x0780
0x07C0

READ THE WAVEFORM DATA OF THE DEVICE (HISTOGRAM)

Function Code = 03, 04
A complete histogram consists of 60 points, one byte representing the value of one point, and only needs to
be transmitted once. Data is transferred from low to high, where the first byte represents the first point, and so
on.
Register Address
0x0B00
0x0B28
0x0B50
0x0B78
0x0BA0
0x0BC8
0x0BF0
0x0C18
0x0C40
Table A- 8 Read the waveform data of the device
Byte Description
128 L1 Grid Voltage Waveform
128 L2 Grid Voltage Waveform
128 L3 Grid Voltage Waveform
128 L1 Load Current Waveform
128 L2 Load Current Waveform
128 L3 Load Current Waveform
128 L1 Comp Current Waveform
128 L2 Comp Current Waveform
128 L3 Comp Current Waveform
128 L1 Grid Current Waveform
128 L2 Grid Current Waveform
128 L3 Grid Current Waveform
Register Start Address = 0x0B00
Table A- 9 Read the waveform data of the device
Byte Description
80 L1 Grid THDU Histogram
80 L2 Grid THDU Histogram
80 L3 Grid THDU Histogram
80 L1 Load THDI Histogram
80 L2 Load THDI Histogram
80 L3 Load THDI Histogram
80 L1 Grid THDI Histogram
80 L2 Grid THDI Histogram
80 L3 Grid THDI Histogram
Remark
Remark
64
