2.3.3 CABINET

2.3.3.1 FLEXIBLE CABINET
Handling facilities are applied for transport through the 4 hanging rings on the top of the cabinet;
Corresponding handling facilities are applied for transport through the bottom of the cabinet.
Note: When moving the cabinet from the bottom of its front, disassemble the front and rear panel at the
bottom. When the cabinet is moved to the designated position, reattach the front and rear.
Figure 2- 6 Cabinet Transportation
Sinexcel flexible cabinet is free-standing cabinet with 4 bearing supports on the ground.
NOTICE
For the flexible cabinet, the distance from the rear side of the unit to the
wall should be at least 800mm, and the front side should be at least
1000mm from the wall to allow for module extraction or insertion.
Please contact Sinexcel if other occasions.
NOTICE
For the flexible cabinet, the distance from the right side of the unit to
the wall should be at least 500mm, and the left side should be at least
500mm from the wall to allow for module extraction or insertion. Please
contact Sinexcel if other occasions.
Figure 2- 7 Lifting Cabinet
