3.2 7-INCH HMI INTRODUCTION

Sinexcel 7-inch HMI is typically used to control multiple modules, making management more convenient. It
features a full touch screen and a colorful visual display for monitoring.
Main page
Figure 3- 2 The position of 7-inch HMI
NOTICE
Ensure and connections are correct, safe and follow the manufacturer's
instructions.
When the module connected with power that the HMI will
initialize.
In main page, user can see the performance directly.
5
