ACQUIRE PARAMETERS OF DEVICE (NO INITIALIZATION)

Function Code = 03, 04
Register start address = 0x2C00
End address = 0x30ff
Register address Byte
No initialization
0x2C00 4
0x2C02 4
0x2C04 4
0x2C06 4
0x2C08 4
0x2C0A 4
0x2C0C 4
0x2C0E 4
0x2C10 4
0x2C12 4
0x2C14 4
0x2C16 4
0x2C18 4
0x2C1A 4
0x2C1C 4
0x2C1E 4
0x2C20 4
0x2c22 4
0x2c24 4
0x2c26 4

READ THE PARAMETERS OF THE DEVICE (EACH HARMONIC COMPENSATION MODE)

A mode is composed of three parameters. The value of each bit represents whether the mode is selected for
the first harmonic. 1 means selection, 0 means no selection.
Table A- 16 Read the parameters of the device (each harmonic compensation mode)
Register address Byte
Initialization
0x3200 4
0x3202 4
0x3204 4
0x3206 4
0x3208 4
0x320A 4
0x320C 4
0x320E 4
0x3210 4

SETTING PARAMETERS OF DEVICE

The parameter setting value is a floating point number. It is represented by 4 bytes. Therefore, the function
code 16 is used to set a single parameter and a plurality of parameters, including general parameters, phase
angle offset parameters, harmonic compensation parameters, and no initialization parameters.
Table A- 15 Acquire Parameters of Device (No Initialization)
Name
L1 Input Voltage Calibration
L2 Input Voltage Calibration
L3 Input Voltage Calibration
Reserved
L1 Inductance Current Calibration
L2 Inductance Current Calibration
L3 Inductance Current Calibration
L1 CT Current Calibration
L2 CT Current Calibration
L3 CT Current Calibration
L1 Inverter Current Calibration
L2 Inverter Current Calibration
L3 Inverter Current Calibration
Clear Fault
CT Zero Point Calibration Enable
Power On
Power Off
Reserved
Reserved
Reserved
Name
2se~24th harmonic compensation mode 1
25th~47th harmonic compensation mode 1
48th~61th harmonic compensation mode 1
2se~24th harmonic compensation mode 2
25th~47th harmonic compensation mode 2
48th~61th harmonic compensation mode 2
2se~24th harmonic compensation mode 3
25th~47th harmonic compensation mode 3
48th~61th harmonic compensation mode 3
Remark
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Greater than 0
Pass 1
Pass 1
( Issue DSP module restart)
Pass 1
Pass 1
Remark
Default 0x7FFFFF
Default 0x7FFFFF
Default 0x7
Default 0
Default 0
Default 0
Default 0
Default 0
Default 0
73
