Functions designed for Marine application.
Connected with the options of "Marine Filter" mode, only
when "Marine Filter" mode is Enabled, this function can be
THDU Limited
used.
(%)
Module can work under the setting limit of THDU. If THDU
exceed the value set by the customer, an alarm will appear in
HMI.
Note: This setting is designed for marine application
requirement, no use in common scenes. Not used for SVG
system;
Functions designed for Marine application.
Connected with the options of "Marine Filter" mode, only
when "Marine Filter" mode is Enabled, this function can be
Unbalanced
used.
Limit (%)
Note: This setting is designed for marine application
requirement, no use in common scenes. Not used for SVG
system;
Limit the biggest output of the machine.
For example, input 0.9 means the biggest capacity of the
machine is 90% of its rated capacity.
Derating Factor
Note: Do not change it without the guidance of Sinexcel
engineer.
Only used by R&D of Sinexcel
Test Mode Note: Prohibit change.
Used for Marine situation.
Connected with THDU Limited (%) and Unbalanced Limit (%),
which need be set when Enable this function.
Marine Filter
Note: Not used for SVG system;
For standard 400V modules, when the IGBT temperature is
higher than 100℃, the module will give an "over-temperature"
alarm and powered off automatically, and when the
temperature is less than 60℃and lasts for 5mins, the module
will automatically on.
Allowed Over
Temp.
For some applications, the customer does not want the
module power on automatically when it's cooling down, they
claim if the alarm is given repeatedly, manual operation will
be required.
"3" means if the module is given "over-temperature" alarm
three times within 24hours, the module will not automatically
on even when the temperature is less than 60℃and lasts for
5mins.
Controller Reserved functions, temporarily closed.
Algorithm
In the past it's for R&D only, will be deleted from the interface.
Connected with Grid Vol. Adjust, which can only be used if
"Grid Vol. Adjust" is Enabled.
Set the voltage upper limit. When the system voltage is above
Vol. Upper Limit
the voltage limit, the machine will compensate the voltage.
(%)
26
0~15% 0.0
0~15% 0.0
0~1 1.0
Enable
Disable
Disable
Enable
Disable
Disable
1-10 3
Enable
Disable
Disable
0~20 (%) 7
Value
Value
Value
N/A
N/A
Value
N/A
Value
(%)
