REQUEST/RESPONSE INFORMATION DETAILS

ACQUIRE STATUS INFORMATION AND ALARMING INFORMATION OF THE DEVICE

Function Code = 02
Status Start Address = 0x0000
Table A- 6Acquire status information and alarming information of the device
Status
Byte
Address
0x0000 1
0x0001 1
0x0002 1
0x0003 1
0x0004 1
0x0005 1
0x0006 1
0x0007 1
0x0008 1
0x0009 1
0x000A 1
0x000B 1
0x000C 1
0x000D 1
0x000E 1
0x000F 1
0x0010 1
0x0011 1
0x0012 1
0x0013 1
0x0014 1
0x0015 1
0x0016 1
0x0017 1
0x0018 1
0x0019 1
0x001A 1
0x001B 1
0x001C 1
0x001D 1
0x001E 1
0x001F 1
0x0020 1
0x0021 1
0x0022 1
0x0023 1
0x0024 1
Description
Initialize flag
Running status
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Dry contact output 1
Dry contact output 2
Dry contact output 3
Dry contact output 4
Dry contact output 5
Dry contact output 6
Dry contact output 7
Dry contact output 8
Lightning arrester failure
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Remark
0: No Initialization,
1: Initialization
0: Standby
1: Run
0: Low level
1: High level
0: Low level
1: High level
0: Low level
1: High level
0: Low level
1: High level
0: Low level
1: High level
0: Low level
1: High level
0: Low level
1: High level
0: Low level
1: High level
0: Normal
1: Abnormal
60
