DRY CONTACT BOARD INSTALL POSITION
For SVG Ultra series module, the dry contact board space is reservced at the rear side of the module.
The red circle below is the position of dry contact board installed in Sinexcel Ultra SVG
Figure A- 44 SVG wall-mounted Ultra dry contact board position
Figure A- 45 SVG rack-mounted Ultra dry contact board position
