2.3.1 WALL-MOUNTED

For wall mount module, the fixing screws are located at the top and bottom of the module. The module must
be fixed vertically to a wall or support, using 4 screws with a diameter of 6mm to be suitable for the chosen
wall or support.
Figure 2- 2 Front Side
NOTICE
For the wall-mount module, the distance from top side of the unit to the
ceiling should be at least 500mm, and the bottom side should be at
least 800mm from the floor.
Figure 2- 3 Rear Side
