3.2.3 PARAMETER SETTING .

The table below are parameters needed to set up Sinexcel 4.3-inch HMI;
Take SVG 100K for example, assuming SVG is used for reactive power compensation, and the CT ratio on
site is 300:5. In the case, the parameters should be set to:
Setting
Operation Mode
Total Capacity
Comp. Rate
CT Ratio
Power On Mode
CT Location
Table 3- 3 Parameter setting in HMI
Operation Mode
Total Capacity
Comp. Rate
Comp. Mode
CT Ratio
Power On Mode
CT Location
Table 3- 4 Case demonstration
Setting parameters
Reactive
150
1.0
300
Manual or Auto
Based on site
