2.5.4 CAN COMMUNICATION CABLE

Note: The function of CAN, which is to communicate between modules.

2.5.5 DIP SWITCH

The dip switch is on the rear side of the module is used when using 7-inch HMI to control rack-mounted LED
modules, which to identify the individual modules by giving them an address via the dip switch.
The dip switch is made by CT1, CT2, CT3 and CT4., which are four contacts.
They're two status of the dip switch, 0 and 1.
NOTICE
When you parallel the rack mounted modules that need to connect the
communication cable, which to meet the communicate between the
modules.
Figure 2- 30 The position of CAN
Figure 2- 31 The position of DIP SWITCH
Table 2- 7 The definition of dip switch
Status Description
0 When dip switch down, "0" stands for "off"
1 When dip switch up, "1" stands for "on"
48
