CHAPTER III COMMISSIONING

3.1 4.3-INCH HMI INTRODUCTION

For the 4.3-inch HMI, which only support in Sinexcel Ultra wall-mounted module;
Sinexcel 4.3-inch HMI is a fully touchscreen, color visualizing and intelligent monitoring system, which is a
leading provider of power electronics solutions. It provides real-time monitoring of power distribution systems,
helping users to quickly identify and diagnose any issues that may arise.
Figure 3- 1 The position of 4.3-inch HMI
NOTICE
Ensure and connections are correct, safe and follow the manufacturer's
instructions.
When the module connected with power that the
HMI will initialize.
Main Page
After initialized, which the HMI shows the 'Grid
Current' and 'Load Current' automatically, and
shows the value in time;
