ACQUIRE PARAMETERS OF DEVICE (PARAMETER OF PHASE ANGLE OFFSET)

Function Code = 03, 04
Register start address = 0x2500
Table A- 13 Acquire Parameters of Device (Parameter of Phase Angle Offset)
Register Address
0x2500
0x2502
0x2504
0x2506
0x2508
0x250A
0x250C
0x250E
0x2510
0x2512
0x2514
0x2516
0x2518
0x251A
0x251C
0x251E
0x2520
0x2522
Byte Name
Initialization
4 Fundamental phase angle offset
4 3rd harmonic phase angle offset
4 5th harmonic phase angle offset
4 7th harmonic phase angle offset
4 9th harmonic phase angle offset
4 11th harmonic phase angle offset
4 13th harmonic phase angle offset
4 L1 phase angle offset
4 L2 phase angle offset
4 L3 phase angle offset
4 2se harmonic phase angle offset
4 4th harmonic phase angle offset
4 6th harmonic phase angle offset
4 8th harmonic phase angle offset
4 10th harmonic phase angle offset
4 12th harmonic phase angle offset
4 14th harmonic phase angle offset
4 15th harmonic phase angle offset
68
Remark
[-40, 40]
Accuracy: 0.1
Default: 0
[-180, 180]
Accuracy: 0.1
Default: 0
[-180, 180]
Accuracy: 0.1
Default: 0
[-180, 180]
Accuracy: 0.1
Default: 0
[-180, 180]
Accuracy: 0.1
Default: 0
[-180, 180]
Accuracy: 0.1
Default: 0
[-180, 180]
Accuracy: 0.1
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
[-180, 180]
Accuracy: 0.01
Default: 0
