1.4.1 PRODUCT DRAWINGS__400V CE SVG MODULE
Please refer to Fig. 1-10 for the appearance and size of Ultra CE 400V 30kVAr wall-mounted type.
Please refer to Fig. 1-11 for the appearance and size of Ultra CE 400V 30kVAr rack-mounted type.
Please refer to Fig. 1-12 for the appearance and size of Ultra CE 400V 50kVAr wall-mounted type.
Please refer to Fig. 1-13 for the appearance and size of Ultra CE 400V 50kVAr rack-mounted type.
Please refer to Fig. 1-14 for the appearance and size of Ultra CE 400V 100kVAr wall-mounted type.
Please refer to Fig. 1-15 for the appearance and size of Ultra CE 400V 100kVAr rack-mounted type.
Please refer to Fig. 1-16 for the appearance and size of Ultra CE 400V 200kVAr wall-mounted type.
Please refer to Fig. 1-17 for the appearance and size of Ultra CE 400V 200kVAr rack-mounted type.
Note: Sinexcel Ultra series, the standard wall mounted is with LCD, the standard rack mounted is with LED. If
needs other type module, please discuss with Sinexcel's engineer.
Figure 1- 10 Sinexcel Ultra CE 400V 30kVAr wall-mounted
Figure 1- 11 Sinexcel Ultra CE 400V 30kVAr rack-mounted
Figure 1- 12 Sinexcel Ultra CE 400V 50kVAr wall-mounted
Figure 1- 13 Sinexcel Ultra CE 400V 50kVAr rack-mounted
16
